Digital Signal Processors (DSPs)

DBX 223xs XLR Crossover

DBX Professional

AED 899 inc VAT.

The 223s by dbx is a dual channel, stereo 2-way or mono 3-way crossover designed to optimize PA system performance by filtering input signals into specific frequency ranges. It features Linkwitz-Riley 24dB per octave filters, independent output gain controls, output phase inversion, a 40Hz low cut filter, and an optional mono summing subwoofer output. Built with high-quality components, the 223s ensures precise control, superior sound clarity, and rugged reliability with solid “click” controls and XLR inputs and outputs.

In stock
Request Quote
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: DBX223XSV-UK Categories: , , Brand:

Description

The 223s from dbx is a versatile dual-channel crossover designed for optimal PA system efficiency. With a stereo 2-way and mono 3-way configuration, it precisely filters the full-band input signal to match the speaker’s frequency range. This ensures the amplifier’s power is fully utilized, minimizing distortion and delivering clear sound.

Featuring Linkwitz-Riley 24dB per octave filters, this unit offers independent output gain controls for level matching, output phase inversion, and a 40Hz low-cut filter. Additionally, it provides an optional mono summing of the low-frequency output for subwoofers. Constructed with high-quality components, it is engineered for excellent sound quality and reliability, complemented by robust XLR inputs and outputs.

Key Features

Specification Details
Stereo Crossover Mode Stereo 2-way, Mono 3-way
Filters 24dB per octave Linkwitz-Riley filters
Subwoofer Output Low frequency summed output
Frequency Range Switch Available on both channels (x10)
Low-Cut Filter 40Hz high-pass filter on both channels
Output Phase Phase reverse switch on all outputs
Output Controls Individual level controls on all outputs
Mode Indicators Stereo/Mono status LEDs
Connections XLR balanced inputs and outputs
Certifications CSA NRTL/C approved, CE compliant
