Yamaha PX5 500W Stereo Power Amplifier

Yamaha

AED 2835 inc VAT.

The Yamaha PX5 Stereo Power Amplifier delivers 500W at 8 Ohms and features a Class-D engine with a custom LSI chip, using PLL technology for efficiency and low noise. It includes on-board DSP functions like PEQ, delay, crossover, and limiter, with a Configuration Wizard for optimized speaker settings and storage for up to eight presets, making it suitable for versatile sound-reinforcement applications.

In stock
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: PX5 Categories: , Brand:

Description

Yamaha PX5 Stereo Power Amplifier

The Yamaha PX5 Stereo Power Amplifier delivers robust 500W output at 8 Ohms in a remarkably lightweight design, making it an ideal choice for diverse sound-reinforcement applications. A standout in Yamaha’s PX Series, this amplifier uses a custom Class-D engine with a single LSI chip and PLL technology, ensuring high efficiency and minimal noise. The Power Boost mode is capable of combining dual-channel outputs to ramp up single-channel power.

Equipped with on-board DSP functions, including PEQ, delay, crossover, and limiter, the PX5 allows intricate tuning of input & output routing, input sensitivity, amplifier gain, and speaker impedance. The D-Control dynamic processor helps maintain clear and consistent audio across various output levels, tailor-fitting sound to both front-of-house and monitor setups.

The Configuration Wizard expedites setup by automatically assigning settings optimized for your speaker setup. Whether in basic or advanced mode, users can store up to eight presets and transfer settings via USB for deploying on other amplifiers. The panel-locking function ensures your configurations stay secure during extensive transport.

Key Features

  • Class-D amplifier with custom LSI chip and PLL technology
  • Power Boost Mode enhances single-channel power
  • Comprehensive DSP functionality: PEQ, crossover, filters, delay, and limiter
  • D-Contour multi-band dynamic processor for tailored audio
  • Basic and advanced setup modes available
  • Versatile connectivity with XLR, TRS, SpeakON, and binding post outputs
  • Durable, road-ready chassis

Specifications

Specification Details
Number of Channels 2
Power Rating 8 Ohms: 500W/channel
4 Ohms: 800W/channel
2 Ohms: 500W/channel
Amplifier Class Class-D
Frequency Response 20 Hz to 20 kHz ±1 dB
Input Impedance 10 kOhms (Unbalanced), 20 kOhms (Balanced)
Max Gain 36.3 dB
Max Input Level +24 dBu
SNR 100 dB
THD+N 0.1% (at 10 W), 0.3% (at 500 W)
Crosstalk < -60 dB
Sample Rate 48 kHz
AD/DA Conversion 24-bit, 128 x Over-Sampling
Latency 1.5 ms
Audio Delay Up to 74 ms
EQ 6-Band Parametric EQ
Filters High-Pass: 20 Hz to 20 kHz, Low-Pass: 20 Hz to 20 kHz
Limiting Yes
Analog Audio I/O XLR, TRS, SpeakON, Binding Post Outputs
USB USB-A (2.0)
AC Input Power 120 VAC, 60 Hz
Power Consumption 230 W (4 Ohms, 1/8 Power), 55 W (Idle)
Cooling Variable Speed Fans
Operating Temperature 32 to 104°F (0 to 40°C)
Dimensions 18.9 x 3.5 x 15.3 inches
Weight 15.2 lb (6.9 kg)
