Yamaha MG12XU 12-Input Mixer with FX and USB Interface

Yamaha

AED 1821.75 inc VAT.

The Yamaha MG12XU is a versatile compact mixer with twelve simultaneous inputs, including four mono mic/line combo channels, two stereo line input channels, and two additional stereo line inputs. It supports USB connectivity, providing 24-bit / 192kHz recording capabilities. Channels 1-8 feature D-PRE mic preamps with 3-band EQ, pan control, high pass filter, 48V phantom power, and attenuation switches. Outputs include XLR and TRS stereo outs, a 1/4″ headphone jack with level control, and additional TRS monitor outs.

In stock
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: MG12XU Categories: , , Brand:

Description

Yamaha MG12XU Mixer

The Yamaha MG12XU is a versatile and compact mixer designed for an array of audio applications, from live performances and recording sessions to lectures and presentations. With twelve simultaneous input channels and robust DSP effects, this mixer delivers exceptional audio quality and user-friendly features to both novice and experienced users.

Key Features

Specification Details
Built-in Effects SPX algorithm: 24 programs, PARAMETER control:1, FOOT SW:1 (FX RTN CH on/off)
Phantom Power +48 V switchable, channels 1 – 4
Digital I/O USB: USB Audio Class 2.0 compliant; Sampling frequency: max 192 kHz; Bit depth: 24-bit
Input Channels 4x mono [mic/line], 2x mono/stereo [mic/line], 2x stereo [line]
Output Channels 2x stereo out, 1x monitor out, 1x headphone out, 2x aux out, 2x group out
Bus Stereo: 1, AUX: 2, GROUP: 2
Compressor Threshold: +22 dBu to -8 dBu, Ratio: 1:1 to 4:1, Output level: 0 dB to 7 dB, Attack time: approx. 25 msec, Release time: approx. 300 msec
Equalizer EQ high gain: +15 dB/-15 dB, Frequency: 10 kHz shelving; EQ mid gain: +15 dB/-15 dB, Frequency: 2.5 kHz peaking; EQ low gain: +15 dB/-15 dB, Frequency: 100 Hz shelving
LED Peak LED turns on when post EQ signal reaches 3 dB below clipping
Level Metering 2 x 12-segment LED meter [PEAK, +10, +6, +3, 0, -3, -6, -10, -15, -20, -25, -30 dB]
Total Harmonic Distortion 0.03% @ +14 dBu (20 Hz to 20 kHz), GAIN knob: Min, 0.005% @ +24 dBu (1 kHz), GAIN knob: Min
Frequency Response +0.5 dB/-1.5 dB (20 Hz to 48 kHz), refer to the nominal output level @ 1 kHz, GAIN knob: Min
Equivalent Input Noise -128 dBu (mono input channel, Rs: 150 Ω, GAIN knob: max)
Residual Output Noise -102 dBu (STEREO OUT, STEREO master fader: min)
Crosstalk -78 dB
Power Requirement AC 100 – 240 V, 50 / 60 Hz
Power Consumption 22 W
Dimensions 12.1 x 4.6 x 16.6″ (308 x 118 x 422 mm)
Net Weight 9.3 lb (4.2 kg)
Package Weight 13.05 lb
Box Dimensions (LxWxH) 19.1 x 15.6 x 8″
