Yamaha AG03 3-Channel Mixer with USB Audio Interface

AED 729.75 inc VAT.

The Yamaha AG03 is a versatile 3-input mixer and USB interface designed for high-resolution 24-bit/192 kHz audio recording and playback, featuring built-in DSP, an XLR/1/4″ combo input, stereo line inputs, and Hi-Z switch for direct guitar/bass recording. Compatible with Windows, Mac, and iPad, it is ideal for small performances, podcasts, and lectures.

In stock

Estimated Delivery: 2–3 business days across the UAE
Free Shipping & Returns : On all orders over AED 1000

Guaranteed Safe And Secure Checkout

Description

Yamaha AG03 3-Input Mixer and USB Interface

The Yamaha AG03 is a versatile 3-input mixer and USB interface designed for various applications such as small performances, podcasts, and lectures. It combines professional-level sound with ease of use and compact design, making it an ideal choice for both home and portable setups.

Key Features

High-Resolution Audio: Capable of recording and playback in stunning 24-bit/192 kHz resolution.
Flexible Inputs: One XLR/1/4″ combo mic/line input, stereo 1/4″ line inputs with level control, and Hi-Z switch for direct recording of guitar and bass.
D-PRE Mic Preamp: XLR/1/4″ combo input with Yamaha’s renowned D-PRE mic preamp, offering switchable 48V phantom power and a pad switch.
Comprehensive Outputs: Equipped with stereo 1/4″ and RCA outs for PA systems or monitor speakers, and a 1/4″ headphone output for personal monitoring.
On-Board DSP: 1-TOUCH DSP adds compression, EQ, and reverb to the signal path, with further customization available through the AG DSP Controller software.

Specifications

Specification	Details
Phantom Power	+48 V
Input Channels	Mono [MIC/LINE]: 1 Stereo [LINE]: 1 Aux: 1
Output Channels	Monitor Out: 2 Phones: 2 including headset phones
Bus	Stereo: 1
Pad	26 dB
Meter Peak Indication	LED turns on when the signal reaches 3 dB below clipping level
DSP	CH1: COMP / EQ, EFFECT (SPX Reverb)
Level Metering	USB Output Level; 2 x 2-point LED meter [PEAK, SIG]
USB Audio	2 in / 2 out, USB Audio Class 2.0 compliant Sampling Frequency: Max 192 kHz Bit Depth: 24-bit
Power Requirements	DC 5 V, 500 mA
Power Consumption	Max. 2.5 W
System Requirements	Windows 7 or later / Mac OS X 10.7 or later (Now compatible with Mac OS 10.12 Sierra)
Options	Footswitch: FC5, Mic Stand Adapter: BMS-10A
Operating Temperature	32 to 104°F (0 to 40°C)
Dimensions	5.1 x 2.5 x 8.0″ (129 x 63 x 202 mm)
Weight	2.2 lb (1.0 kg)
