Turbosound MV212-XV Dual 12″ Passive Line Array Speaker 3160W Peak

Turbosound

AED 18,843.30 inc VAT.

In stock
Enquiry On Whatsapp
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: MV212-XV Categories: , Brand:

The Turbosound Manchester Series MV212-XV is a dual 12″ 3-way passive line array speaker, ideal for touring, portable, and installed sound applications such as nightclubs and concert halls. It integrates seamlessly with a separate Lab Gruppen PLM+ amplifier for optimized performance, with the ability to suspend up to 16 units for versatile FOH setups.

Description

The Turbosound Manchester Series MV212-XV is a full-size, dual 12″ 3-way passive line array speaker element well suited for touring, portable, and installed sound reinforcement applications including nightclubs, concert halls, houses of worship, and more. The MV212-XV is designed to be seamlessly integrated with a Lab Gruppen PLM+ amplifier (sold separately), which offers meticulously designed presets that allow for maximum system performance and consistency. Up to 16 MV212s can be suspended, making this line-array an optimal FOH solution with flexibility that’s adaptable to varying venue requirements.

Two 12″ woofers with neodymium motors and a single dual-concentric MF/HF compression driver deliver remarkable clarity and intelligibility in a compact enclosure. Due to its broad 100° horizontal by 10° vertical dispersion pattern, the MV212-XV provides exceptional coverage in wide rooms and in distributed fill applications.

Key Features

  • For Sound Reinforcement Applications
  • 3160W Peak Power Handling
  • Designed for Lab Gruppen PLM+ Amplifiers
  • Dual 12″ Low-Frequency Neodymium Woofers
  • 1.4″ Coaxial Mid-High Compression Driver
  • 3-Point Suspension System
  • Suspend up to 16 x MV212-XV Elements
  • Weather-Resistant Enclosure

Specifications

PA Speaker Details
Configuration Passive 3-Way
Enclosure Type Bass-Reflex Line Array
Total Power Capacity 3160 W Peak
Amplifier Power Rating LF: 1 x 2400 W Peak (at 8 Ohms)
HF/MF: 1 x 760 W Peak
System Impedance LF: 2 x 8 Ohms (Bi-Amp)
HF: 1 x 12 Ohms (Bi-Amp)
Drivers Details
HF Driver 1 x 1.4″ / 35.56 mm Horn-Loaded Compression Driver
MF Driver None
MF Voice Coil None
LF Driver 2 x 12″ / 304.8 mm Woofer
Magnet Neodymium
Performance Details
Frequency Response 50 Hz to 20 kHz -3 dB
35 Hz to 20 kHz -10 dB
Maximum SPL 143 dB
Coverage Angle 100° H x 10° V
Speaker Sensitivity LF: 101 dB
HF/MF: 117.5 dB
Connectivity Details
Audio I/O 2 x speakON NL4 Speaker Input/Thru (Lockable)
Signal Processing Details
Crossover Bi-Amp
EQ Yes
Mounting Integrated Rigging
Construction Material Plywood
Dimensions 31.9 x 19.3 x 13.9″ / 810.3 x 490.2 x 353.1 mm
Weight 110.2 lb / 50 kg
