Toa Mixer Amplifier A-5006 60W with 2 Mic/Line Inputs

Toa

AED 2752.05 inc VAT.

In stock
Enquiry On Whatsapp
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: A-5006 1CE Categories: , , Brand:

The A-5006 is a versatile half-rack, 1-unit desktop mixer power amplifier delivering 60 W. With configurable MIC/LINE inputs and compatibility with both high and low impedance outputs, it suits various sound setups. This amplifier’s features can be customized through dedicated PC software, making it ideal for small commercial facilities and conference rooms. Optional rack mounting allows installation in standard EIA equipment racks.

Description

A-5006 Desktop Mixer Power Amplifier

The A-5006 is a versatile half-rack, 1-unit size 60 W desktop mixer power amplifier, perfect for small commercial facilities and conference rooms. This highly adaptable unit supports both MIC and LINE sound sources for inputs 1 and 2, and works with both high-impedance (100 V and 70 V lines) and low-impedance (4 Ω) speaker connections. The amplifier’s settings can be configured with a PC using dedicated software, and it can be rack-mounted in an EIA Standard equipment rack with an optional bracket.

Key Features

  • 60 W output power
  • Two mic/line inputs with mute function
  • 5-band Parametric Equalizer for each input and output (DSP)
  • Remote Master Volume Control
  • Input 1 priority mute (manual mute)
  • Compressor for input 1 and 2

Specifications

Specification Details
Power Source 100 – 240 V AC, 50 / 60 Hz
Rated Output 60 W
Frequency Response 50 Hz – 20 kHz (1/8 rated output)
Distortion < 1 % (at 1 kHz, rated power)
Power Consumption 106 W (at rated output)
Speaker Output 4 Ω, 70 V (83 Ω), 100 V (170 Ω), removable terminal block (5 pins)
S/N Ratio 70 dB(A) (LINE 1–4: 70 dB(A) or more, MIC 1,2: 50 dB(A) or more)
Number of Channels 1
Connectable Microphones 2
Inputs INPUT 1, 2: MIC -60 dBV, LINE -20 dBV, MIC/LINE selectable; 2.2k Ω, electronically-balanced, removable terminal block (5 pins); INPUT 3, 4: LINE -20 dBV, 10k Ω, unbalanced, RCA pin jack
Control Input Mute control, Remote master volume control
Outputs Speaker: 4 Ω, 70 V (83 Ω), 100 V (170 Ω), removable terminal block (5 pins)
Finish Polystyrene resin, Steel plate, paint, black
Dimensions 210 x 52.5 x 375 mm (W x H x D)
Weight 3.6 kg
Accessory (included) CD (setting software) x1, Large removable terminal plug (5 pins) x1, Small removable terminal plug (5 pins) x2, Plain washer x6, Bracket mounting screw (M3 x 10) x6, Power supply cord (2 m) x1
