Toa Digital Mixer Amplifier A-3648D 480W Class D for Public Address

Toa

AED 5,515.65 inc VAT.

In stock
Enquiry On Whatsapp
  • Check Mark Estimated Delivery: 2โ€“3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: A-3648D 4CEE00 Categories: , , Brand:

The A-3600D Series Digital Mixer Amplifier offers up to seven inputs and 480 W of power, with browser-based control for easy remote management. Featuring a feedback suppressor, input priorities, and sleek design, it’s ideal for music, paging, and noise masking in various settings such as retail shops, schools, offices, and factories. Equipped with zone selectors, high and low impedance options, and emergency paging, this energy-efficient amplifier ensures clear audio quality and reliable performance.

Description

A-3600D Series Digital Mixer Amplifier

The A-3600D Series Digital Mixer Amplifier provides a blend of flexibility and high performance. With up to seven audio inputs and a powerful 480 W Class D amplifier, it is designed for diverse audio applications such as background music, paging, and noise masking in various settings such as retail, educational institutions, and offices. The series features browser-based control for convenient system management from any location, making it an efficient solution for modern public address requirements.

Key Features

  • Supports high and low impedance speakers
  • Operates on 100V – 240V AC mains
  • Includes 8 audio inputs (4 MIC/AUX, 2 MIC, 1 AUX, 1 power amp)
  • 4 microphone inputs with phantom power
  • 2-zone speaker selector for high impedance
  • Dual line-out options
  • Dedicated recording output
  • Zone control inputs/outputs and power remote control output
  • Emergency paging capabilities

Specifications

Power Source 100 – 240 V AC, 50 / 60 Hz
Rated Output 480 W
Frequency Response 50 Hz – 20 kHz (ยฑ3 dB)
Distortion < 1 % (at 1 kHz, rated power)
Power Consumption 113 W (EN62368-1), 601 W (rated output)
Speaker Output Low impedance: 4-16 ฮฉ, High impedance: 100 V, direct, zone 1, zone 2
Amplifier Class D
S/N Ratio 88 dB (A-weighted)
Connectable Microphones 6
Controls 7x volume inputs, bass, treble, master volume, zone 1 & 2 switch, power
Inputs Input 1+2: -60/-20 dBV, 600 ฮฉ, balanced, phantom power switchable;
Input 3+4: -60 dBV, 600 ฮฉ, balanced, phantom power switchable;
Input 5+6: -60 dBV, 600 ฮฉ, balanced; -20 dBV, 10 kฮฉ, unbalanced;
Input 7: -20 dBV, 10 kฮฉ, unbalanced
Control Input 4 channels, no-voltage make contact input
Outputs Recording, Line out 1+2: 0 dBV, 600 ฮฉ, unbalanced
Control Output Power remote, emergency, zone control
Operating Humidity 85 % RH or less (no condensation)
Operating Temperature -10 ยฐC to +40 ยฐC (14 ยฐF to 104 ยฐF)
Finish ABS resin, paint, black, Surface-treated steel plate
Dimensions (W x H x D) 420 x 96.1 x 313.1 mm
Accessories (included) Power cord, Audio input removable terminal plugs, Control I/O removable terminal plugs, Remote control plugs, Speaker out terminal plug, Volume control cover
