Tascam VS-R264 Full HD Streaming Encoder with H.264 and RTMP Support

Tascam

AED 7,294.35 inc VAT.

In stock
Enquiry On Whatsapp
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: VS-R264 Categories: , Brand:

The VS-R264 is a Full HD AV over IP device that records, encodes, streams, and decodes 1920×1080 video using H.264 long GOP encoding with bit rates up to 30 megabits, compatible with 100Mbps and 1Gbps networks.

Description

VS-R264 Full HD AV Streaming Encoder/Decoder

The VS-R264 is a cutting-edge Full HD AV over IP streaming encoder and decoder offering simultaneous recording, encoding, streaming, and decoding of 1920×1080 video streams. Utilizing H.264 long GOP encoding, it achieves bit rates up to 30 megabits over standard networks, making it perfect for various high-demand environments.

Key Features

  • Simultaneous recording, encoding, streaming, and decoding of Full HD video streams.
  • Compatibility with major streaming protocols like RTMP, RTSP, and HLS.
  • Supports Full HD streaming to CDNs such as YouTube, Wowza, and AWS Elemental MediaLive.
  • Versatile audio I/O connections, including balanced analog Euroblock and unbalanced mini-stereo jacks.
  • Embedded and de-embedded audio for networked audio playback and ceiling speakers.
  • Recording capabilities to USB, SD cards, and internal 17GB storage.
  • Web browser-based remote control for easy configuration.
  • Compact design with rack-mountable options available.

Specifications

Specification VS-R264 VS-R265
Video inputs and outputs
HDMI IN HDMI v1.4a (Type A receptacle)
HDMI OUT HDMI v2.0 (Type A receptacle)
Input Resolutions
2160p – 30 / 29.97 / 25 / 24 / 23.98 fps
1080p 60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98 fps
720p 60 / 59.94 / 50 fps
576p 50 fps
480p 60 / 59.94 fps
Frame Rate Limiting on/off
Encode Scaling Resolutions Passthrough / 1920x1080p / 1280x720p / 950x540p / 720x576p / 720x480p / 640x360p / 480x270p / 320x180p Passthrough / 3840x2160p / 1920x1080p / 1280x720p / 950x540p / 720x576p / 720x480p / 640x360p / 480x270p / 320x180p
Encoding Format H.264 H.264 / H.265
Encoding bitrates 500k to 30M bps
Bit rate Control Variable, Constant
Key frame interval
Seconds 0.25 – 16.5 (default: 1) in 0.25 intervals
Frames 3 – 1000
Video streaming
Supported protocols RTMP, RTMPS, RTSP, HLS, RTP, UDP (Note: Some servers may not support H.265)
Number of simultaneous streams 8 (3 x RTMP/RTMPS, 1 x RTSP, 1 x HLS, 2 x RTP/UDP Unicast, 1 x RTP/UDP Multicast)
Audio inputs and outputs
ANALOG IN (BALANCED)
Connectors Euroblock (balanced) 3.81 mm pitch
Nominal input level +4dBu (1.23Vrms), +6dBu (1.55Vrms)
Maximum input level +15dBu (4.36Vrms), +18dBu (6.16Vrms), +20dBu (7.75Vrms)
Input impedance 10 kΩ or higher
ANALOG IN (UNBALANCED)
Connector 3.5mm (1/8″) stereo mini jack
Nominal input level -10dBV (0.316Vrms)
Maximum input level +6dBV (2.0Vrms)
Input impedance 10 kΩ
ANALOG OUT (BALANCED)
Connectors Euroblock 3.81 mm pitch
Nominal output level +4dBu (1.23Vrms), +6dBu (1.55Vrms)
Maximum output level +15dBu (4.36Vrms), +18dBu (6.16Vrms), +20dBu (7.75Vrms)
Output impedance 200Ω or lower
ANALOG OUT (UNBALANCED)
Connector 3.5mm (1/8″) stereo mini jack
Nominal output level -10dBV (0.316Vrms)
Maximum output level +6dBV (2.0Vrms)
Output impedance 200Ω
Output Volume -∞, -72 to +6dB (1dB step)
Audio Codec AAC, 64k to 512k bps, 32k/44.1k/48k Hz
Video / audio recording
Recording media USB Drive, SD/SDHC card, Internal storage
Recording format MPEG2-TS, MPEG4
Recording bit rates 500k to 30M bps
Control input/output
ETHERNET / PoE+
Connector RJ-45
Transmission protocol TCP/IP, UDP, HTTP
Gigabit Ethernet standard 1000BASE-T (IEEE 802.3ab)
Cables Category 5e or faster STP cables
USB
Connector USB A-type 4-pin
Protocol USB 2.0, USB 3.0
Other
Power PoE Plus Class 4, TASCAM PS-P1220E AC adapter (sold separately)
Power consumption 12.2W
Dimensions 214(W) × 44.5(H) × 136.1(D)mm
Weight 850g
Operating temperature range 0 to 40 °C
Included items Installation brackets x2, Euroblock plugs x4, Cable band kit, USB memory (with TASCAM DISCOVERY, reference Manual), Quick Start guide (Warranty)
