Tascam MZ-123BT Multi-Zone Audio Mixer with Bluetooth Connectivity

Tascam

AED 2391.90 inc VAT.

The Tascam MZ-123BT Multi-Zone Audio Mixer is a compact 1 RU professional installation mixer designed for versatile audio routing, mixing, and distribution, suitable for up to three zones in commercial settings like retail venues, restaurants, bars, cafes, and hotels, and features Bluetooth connectivity.

In stock
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: MZ-123BT Categories: , , Brand:

Description

Tascam MZ-123BT Multi-Zone Audio Mixer with Bluetooth

The Tascam MZ-123BT is a versatile, compact 1 RU multichannel, multi-zone professional installation mixer. It’s designed for routing, mixing, and distributing audio across up to three zones, making it perfect for commercial environments such as retail venues, restaurants, hotels, and more. Equipped with Bluetooth connectivity, this mixer offers an intuitive layout for easy operation.

Key Features

  • Commercial Retail Applications
  • Three-Zone Music Distribution
  • Mono or Stereo Operation
  • Two Microphone Inputs, Two Line Inputs
  • Bluetooth and AUX 3.5mm Inputs
  • Independent Volume Controls
  • 3-Band EQ, HP Filter, Phantom Power
  • 1/4″ Headphone Jack

Specifications

Specification Details
Mic Input Balanced Combo XLR-1/4″ / 6.3mm Jack
Rated Input Level -26 dBu (Front High), -2 dBu (Front Low)
Maximum Input Level -10 dBu (Front High), +14 dBu (Front Low)
Minimum Input Level -65 dBu (Front High), -41 dBu (Front Low)
Gain Adjustment Range 39 dB
Input Impedance 2.4 Kilohms
Rear Mic Connectors Euroblock (Balanced, 3.81 mm Pitch)
Rear Line Connectors RCA
Nominal Input Level -10 dBV (0.316 Vrms)
Maximum Input Level +6 dBV (2.0 Vrms)
Gain Adjustment Range -16 dB to +16 dB
Aux Input Connector (Front) 1/8″ / 3.5mm Stereo Mini-Jack
Aux Nominal Input Level -20 dBV (0.1 Vrms)
Aux Maximum Input Level -4 dBV (0.63 Vrms)
Stereo Output Connector Euroblock (Balanced, 3.81 mm Pitch)
Rated Output Level +4 dBu (1.228 Vrms)
Maximum Output Level +24 dBu (12.282 Vrms)
Output Impedance 200 Ohms
Headphones Output 1/4″ / 6.3 mm Stereo Jack; Max Output: 80 mW + 80 mW (32 Ohms Load)
Bluetooth Version 4.2
Bluetooth Output Class 2 (Approx. 10 m Range)
Supported Profiles A2DP (SBC, AAC, Qualcomm aptX), SCMS-T
Power Supply 100 to 240 VAC, 50/60 Hz
Power Consumption 25 W
Operating Temperature 32 to 104°F / 0 to 40°C
Dimensions 19.02 x 1.83 x 10.82″ / 48.30 x 4.65 x 27.48 cm
Weight 6.6 lb / 3 kg
Package Weight 10.28 lb
Box Dimensions 21.4 x 14.2 x 5.7″
