Tascam MM-4D/IN-X 4-Channel Mic Line Input Dante Converter with DSP Mixer

Tascam

AED 3985.80 inc VAT.

The Tascam MM-4D/IN-X is a 4-channel mic/line input Dante converter that transforms XLR input signals into Dante input/output signals, featuring level control and built-in DSP mixing. It supports Dante Domain Manager for enhanced security and network access, is compatible with AES67 network systems, and includes two installation brackets.

In stock
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: MM-4D/IN-X Categories: , Brand:

Description

Tascam MM-4D/IN-X 4-Channel Mic/Line Input Dante Converter with Built-In DSP Mixer

The MM-4D/IN-X from Tascam is a versatile 4-channel mic/line input converter designed to integrate seamlessly into professional audio setups. Equipped with Dante networking capabilities and a built-in DSP mixer, this device allows you to efficiently convert XLR input signals into Dante network signals, enhancing your audio system’s flexibility and control.

The converter supports PoE for easy power management and can be controlled remotely via Dante. With robust compatibility features, secure network integration via Dante Domain Manager, and support for AES67 network systems, the MM-4D/IN-X is well-suited for diverse audio environments. Its compact size allows it to be mounted in various locations, making it a practical choice for both studio and live applications.

Key Features

  • 4-channel mic/line input with phantom power (+48V) support on 3-pin XLR connectors
  • 4 Dante inputs/outputs with level control
  • Supports Power over Ethernet (PoE)
  • Sample rate up to 24-bit / 96 kHz
  • Dante daisy-chaining capability without a network switch
  • Compact half-rack mountable design
  • Two user-control software options: TASCAM DCP CONNECT for integrators and TASCAM EZ CONNECT for end-users
  • Remote control capabilities via Dante network
  • Visual indicators for LAN/Dante connection status and sample rate

Specifications

Specification Details
Formats Supported 44.1/48/88.2/96 kHz, 16/24-Bit, 4 Channels
Connector (Input/Output) RJ-45
Transmission Protocol Dante
Ethernet Standard 1000 BASE-T (IEEE 802.3ab)
Cable Requirements Category 5e or Faster STP Cables
Analog Input Connector 3-Pin XLR
Input Levels Min: -70 dBu, Max: +26 dBu
Input Impedance 2.0 kOhms or Higher
Equivalent Input Noise -125 dBu
Frequency Response ±0.5 dB: 20 Hz – 40 kHz
Distortion 0.003%
Signal to Noise Ratio 108 dB
Crosstalk 100 dB
Dynamic Range 108 dB
Power PoE Class 0, Optional Tascam PS-P1220E AC Adapter
Power Consumption 7.5 W
Operating Temperature 32 to 104°F / 0 to 40°C
Dimensions 8.4 x 1.7 x 5.4″ / 21.4 x 4.4 x 13.6 cm
Weight 31.2 oz / 885 g
Package Weight 2.94 lb
Box Dimensions (LxWxH) 10.95 x 8.3 x 4.2″
