Tascam MM-4D/IN-E 4-Channel Mic/Line Input Dante Converter with DSP Mixer

Tascam

AED 3985.80 inc VAT.

The MM-4D/IN-E 4-Channel Mic/Line Input Dante Converter from Tascam converts 4-channel mic/line input signals on Euroblock connectors into Dante input/output signals, featuring level control and compatibility with Dante Domain Manager software for enhanced security and network integration. It supports AES67 for connection to AES67 networks and includes two installation brackets.

In stock
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: MM-4D/IN-E Category: Brand:

Description

Tascam MM-4D/IN-E 4-Channel Mic/Line Input Dante Converter with DSP Mixer

The Tascam MM-4D/IN-E is a versatile 4-channel mic/line input Dante converter designed to transform Euroblock connectors into Dante input/output signals, ideal for professional audio applications. With its built-in DSP mixer, it offers superior sound quality and operational flexibility.

Features

  • 4-channel mic/line input with phantom power (+48V) on Euroblock connectors
  • Supports Dante Domain Manager for secure network management and AES67 mode for broader network compatibility
  • Power over Ethernet (PoE) capability
  • Sample rates of up to 24-bit / 96 kHz
  • Dante daisy-chain support for seamless connection of multiple devices
  • Flexible scene preset function with up to 50 presets
  • User-friendly control software for Windows, Mac, iOS, and Android
  • Remote control via Dante network
  • Half-rack size for easy installation
  • Includes indicators for LAN/Dante connection and signal status
  • Configurable reference level via remote control
  • Surface-mount adapters for under-desk installation

Specifications

Specification Details
Formats Supported 44.1/48/88.2/96 kHz, 16/24-Bit, 4 Channels
Connector RJ-45
Transmission Protocol Dante
Gigabit Ethernet 1000 BASE-T (IEEE 802.3ab)
Cable Category 5e or Faster STP Cables
Analog Inputs Euroblock (Balanced) 3.81 mm Pitch
Minimum Input Level -70 dBu
Maximum Input Level +26 dBu
Input Impedance 2.0 kOhms or Higher
Control Interface Euroblock (Balanced) 3.81 mm Pitch
Frequency Response ±0.5 dB: 20 Hz – 20 kHz (44.1/48 kHz Sampling), ±0.5 dB: 20 Hz – 40 kHz (88.2/96 kHz Sampling)
Distortion 0.003 % (when −1 dBFS Input, 44.1/48/88.2/96 kHz Sampling)
Signal to Noise Ratio 108 dB
Crosstalk 100 dB
Dynamic Range 108 dB
Power PoE Class 0, Tascam PS-P1220E AC Adapter (Sold Separately)
Power Consumption 7.5 W
Operating Temperature 32 to 104°F / 0 to 40°C
Dimensions 8.4 x 1.7 x 5.4″ / 21.4 x 4.4 x 13.6 cm
Weight 31.2 oz / 885.0 g
Package Weight 2.925 lb
Box Dimensions (LxWxH) 12.7 x 10.7 x 3.9″
