TASCAM MM-2D-E Dante Compact Processor

The MM-2D-E is a compact converter that effectively transforms 2-channel mic/line input and output signals into Dante signals. With half the size of a standard 1U rack, this unit is designed to suit various Dante systems, acting as an extraordinary analog output unit. Featuring a built-in DSP mixer, it allows small scale systems to fully utilize the numerous input/output models that the TASCAM Dante Compact Processor Series offers. The MM-2D-E supports up to 96kHz/24bit and implements Euroblock connectors for analog mic/line input/output.

Features

• 2-channel mic/line input with phantom power (+48V) support
• Remote mic gain control capability
• 2 line outputs
• 4 Dante inputs/outputs
• Power over Ethernet (PoE) support
• High-resolution audio up to 24bit/96kHz
• Comprehensive DSP functions for different operational environments, including output effects and a 6 in/4 out matrix mixer
• Ability to daisy chain Dante devices without a network switch
• Compatibility with Dante Domain Manager and Dante AES67 Mode
• Scene preset function ensuring adaptability in different areas with up to 50 presets
• Timer event function for automatic scene switching at planned times (future version update expected)
• Two types of user-control software available for Windows/Mac/iOS/Android devices
• Remote control capabilities via GPI and Dante
• Half-rack mountable size ideal for various installations
• Status indicators for LAN, connection status, and sample rate
• Signal indicators for monitoring line input/output signals
• Configurable reference level via remote control
• Surface rack mountable angles included for installation under desks
• Optional accessories: AC adapter PS-P1220E for redundant power and rack-mountable shelf AK-RS1

Specifications
