Tascam ML-4D/OUT-E 4-Channel Line Output Dante Converter with DSP Mixer

TASCAM ML-4D/OUT-E Dante Compact Processor

The ML-4D/OUT-E is a versatile and compact converter designed to convert Dante input signals into 4-channel line output signals. Occupying just half the size of a standard 1U rack, it serves as the perfect analog output unit for various Dante systems. This model includes a built-in DSP mixer, ensuring optimal performance in small-scale setups with other models from the TASCAM Dante Compact Processor Series.

Supporting up to 96kHz/24bit resolution, the ML-4D/OUT-E employs Euroblock connectors for its analog line outputs. Its robust design and powerful features make it an essential equipment in diverse professional audio environments.

Features

• 4 line output channels
• 4 Dante input/output channels
• Supports Power over Ethernet (PoE)
• Sample rates up to 96kHz/24bit
• Built-in DSP functions for enhanced usability
• Dante daisy chain capability
• Compatible with Dante Domain Manager and AES67 modes
• Up to 50 flexible scene presets
• Future support for timer event functionality
• Control software available for Windows, Mac, iOS, and Android
• Remote control via GPI and Dante
• Half-rack mountable size
• Indicators for LAN/Dante connection status and sample rate
• Signal indicators for line output monitoring
• Configurable reference levels via remote control
• Surface rack mountable angles for under-desk installation included
• Optional accessories: redundant power supply adapter, rack-mountable shelf
