Tannoy QCI 6DC In-Wall 6″ Dual Concentric Loudspeaker

Tannoy

AED 1140.30 inc VAT.

Tannoy loudspeakers have been trusted by audio professionals globally for over 90 years due to their reliability, true-to-source accuracy, and exceptional sound reproduction. Ideal for recording, broadcasting, and home listening, they deliver music and sound exactly as the artist intended.

In stock
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: QCI 6DC IW Categories: , Brand:

Description

Tannoy QCI In-Wall Loudspeaker

For over 90 years, Tannoy has been at the forefront of audio excellence, trusted by professionals worldwide for their reliability and accurate sound reproduction. The QCI range embodies the same high standards and innovation, making it ideal for any in-wall installation where quality audio is paramount. Perfect for creating a stereo, surround, or multi-room system, the QCI loudspeakers deliver a natural and detailed listening experience, true to the artist’s original vision.

Features

  • High-performance loudspeaker for in-wall installations
  • 6″ Dual Concentric driver with Tannoy point-source constant directivity
  • Tulip Waveguide for uniform frequency response
  • High-excursion glass fibre cone with rubber surround
  • 70 Watts continuous, 280 Watts peak power
  • Extremely thin bezel for discreet integration
  • Integrated single unit construction for easy installation
  • Semi-matt white finish for unobtrusive appearance
  • UV-resistant perforated steel mesh grille with dust protection
  • Removable grille for custom painting
  • Self-aligning clamp mounting system
  • Removable Tannoy grille badge
  • Over 90 years of British sound heritage and innovation

Specifications

Specification Details
Frequency response (±3 dB) 50 Hz – 20 kHz
Frequency response (-10 dB) 30 Hz – 20 kHz
Sensitivity (1 W @ 1m) 85 dB
Directivity factor (Q) 4.8 averaged 1 kHz to 10 kHz
Directivity index (DI) 6.8 averaged 1 kHz to 10 kHz
Average power handling (IEC) 70 W
Programme power handling (IEC) 140 W
Peak power handling (IEC) 280 W
Recommended amplifier power 210 W @ 8 Ω
Nominal Impedance (Lo Z) 8 Ω
Rated maximum SPL (1 m, Lo Z) 107 dB
Crossover point 1.6 kHz
Coverage angles (500 Hz) 180° horizontal, 160° vertical
Coverage angles (1 kHz) 141° horizontal, 144° vertical
Coverage angles (2 kHz) 119° horizontal, 134° vertical
Coverage angles (4 kHz) 92° horizontal, 87° vertical
Low frequency diameter/material/type 165.5 mm (6″)
High frequency diameter/material/type 25.4 mm (1″)
Back can options Steel, powder coating
Baffle material Reflex loaded UL94 V-0 rated ABS
Grille material Steel, with weather-resistant coating
Clamping design Security toggle clamp
Connectors Phoenix Contact terminal block
Dimensions (HxWxD) 315 x 221 x 105 mm (12.4 x 8.7 x 4.1″)
Net weight 2.9 kg (6.4 lbs)
Included accessories Grille, paint mask, cutout template
Optional accessories BACK CAN IW, PMK 6 IW
