Tannoy Ceiling Loudspeaker CMS 403DCE 4″ Dual Concentric Driver 160W

Tannoy

AED 883.05 inc VAT.

In stock
Enquiry On Whatsapp
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: CMS 403DCE Categories: , Brand:

The CMS 403DCE is a 160-Watt high sensitivity loudspeaker featuring the advanced CMS 3.0 technology and a proprietary 4″ Dual Concentric point-source driver with Omnimagnet technology. Its Torus Ogive Waveguide ensures wide, consistent broadband directivity and enhanced intelligibility, delivering accurate and linear response for excellent audio performance.

Description

CMS 403DCE Full Bandwidth Loudspeaker

The CMS 403DCE is a professionally engineered, high-performance ceiling loudspeaker designed to offer crystal-clear audio in a variety of installation scenarios. Utilising third-generation Ceiling Monitor System technology, this 160-Watt powerhouse is ideal for both commercial and residential environments.

Features

  • 4″ Dual Concentric point-source driver with Omnimagnet technology
  • 160 Watts peak, 40 Watts continuous power handling
  • Torus Ogive Waveguide for enhanced high-frequency response
  • Adjustable tilt and 360° rotation
  • Multiple transformer taps for 70V, 100V, and 16 Ohm systems
  • Quick and easy installation with integrated construction and clamp mounting system
  • Durable and discreet semi-matt white finish
  • Powder-coated UV resistant perforated steel mesh grille

Specifications

Performance

Frequency Response (-3 dB) 110 Hz – 50 kHz
Frequency Range (-10 dB) 80 Hz – 54 kHz
System Sensitivity (1 W @ 1 m) 88 dB
Nominal Coverage Angle 90 degrees conical

Transducers

Dual Concentric Point Source Driver 1 x 100 mm (4.0″) with Omnimagnet technology
Low Frequency 35 mm (1.38″) voice coil with multi-fiber paper pulp cone
High Frequency 20 mm (0.79″) PEI dome

Physical

Safety Features Safety ring for load-bearing safety bond
Clamping Design Min/Max clamping range: 0.0 mm / 20.0 mm, Recommended clamp torque: 1.5 Nm
Accessories C-Ring, tile-bridge kit, paint mask, cut-out template, grille
Optional Accessories Plaster (mud) ring
Packed Quantity 2
