Audio Mixers

Soundcraft Analog Mixing Console Notepad-12FX with 4 Mic Preamps and USB Interface

Soundcraft

AED 1134.97 inc VAT.

In stock
Enquiry On Whatsapp
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: Notepad-12FX Categories: , , Brand:

The Notepad-12FX from Soundcraft is a compact 12-channel analog mixer featuring a 4×4 USB audio interface and built-in Lexicon effects, ideal for music production, podcasts, video content, interviews, rehearsals, writing sessions, and mobile events. It includes four microphone preamps with combo XLR-1/4” inputs, a 3-band EQ, and 100 Hz high-pass filters. Inputs 1 and 3 provide Hi-Z instrument inputs for guitars and other high-impedance instruments.

Description

The Notepad-12FX from Soundcraft is a small-format, 12-channel analog mixing console with an integrated 4×4 USB audio interface and built-in Lexicon effects, well suited for music production, podcasts, video production, interviews, rehearsals, writing sessions, and mobile events. The mixer combines professional-grade analog components such as four microphone preamps with combo XLR-1/4″ inputs, 3-band EQ, and 100 Hz high-pass filters. Additionally, inputs 1 and 3 offer Hi-Z instrument inputs for incorporating guitars and other high-impedance instruments.

Key Features

  • Four Combo XLR-1/4″ Mic/Line Inputs
  • Six 1/4″ Line Inputs and Two RCA Inputs
  • 4-In/4-Out USB Audio Interface
  • Lexicon FX with Delay, Reverb, & Chorus
  • Master XLR Outputs
  • Dedicated Aux Send and Stereo Return
  • Independent Headphone Controls
  • 3-Band EQ & Hi-Z Inputs on Channels 1&3
  • Durable Metal Enclosure

Specifications

Specification Details
Number of Analog Input Channels 12 (4 Mono / 4 Stereo)
Number of Mic Preamps 4
Analog Output Channels 1 x Stereo Master Output, 1 x Mono Aux Send Output, 1 x Stereo Headphone Output
Meters Main Meter: 2 x 4-Segment LED
Meter Range -20 dB to +6 dB Plus Peak/Clip
EQ Parameters High: ±12 dB at 12 kHz, Mid: ±12 dB at 2.5 kHz, Low: ±12 dB at 80 Hz
Built-In Effects Delay, Chorus, Reverb
Analog Inputs 4 x Combo XLR-1/4″ Mic/Line Input, 4 x 1/4″ Line Input, 1 x Stereo RCA Coaxial Line Input, 2 x 1/4″ Line/FX Input
Analog Outputs 2 x XLR 3-Pin Main Output (1 Stereo Pair), 1 x 1/4″ Aux Output, 1 x 1/4″ TRS Headphone Output
USB 1 x USB Type-B
USB I/O Capacity 4 x Input / 4 x Output
Rack Mountable No
Package Weight 4.705 lb
Box Dimensions (LxWxH) 13.6 x 12.05 x 3.6″
