Soundcraft LX7ii 32-Channel Analog Mixer with 6 Aux Sends

Soundcraft

AED 10194.05 inc VAT.

In stock
Enquiry On Whatsapp
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: LX7ii32 Categories: , Brand:

The Soundcraft LX7 II series of professional analog consoles offers 16, 24, and 32 input configurations, enhancing its already impressive feature set for professional recording and live sound applications, with balanced 1/4″ phone line level inputs and direct outputs on the first 32 channels for effective recording and monitoring.

Description

Soundcraft LX7 II Professional Analog Console

The Soundcraft LX7 II series of professional analog consoles enhances its already impressive feature set, crafted to meet the rigorous demands of professional recording and live sound engineers. Available in 16, 24, and 32 input configurations, it offers a versatile solution for various audio scenarios.

Key Features

  • 32 balanced 1/4″ phone line level inputs
  • High-quality redesigned microphone preamps on each input channel
  • 4 subgroup outputs for flexible routing
  • 6 aux sends for routing to external effects and processors
  • 48v phantom power in blocks of 4
  • Advanced EQ section with enhanced controls
  • Direct outputs for recording on most channels
  • LED indicators for peak and solo signals
  • Compact form factor with professional-grade components

Specifications

Specification Details
Total # Of Inputs 32 – Total Line Inputs
Mic/Line Inputs 32 – Balanced 1/4″ TRS Phone Inputs
32 – Balanced XLR Mic Inputs
Stereo Line Inputs 2 – L/R Stereo Paired 1/4″ TRS Phone
AUX Sends 6 – 1/4″ TRS Phone
AUX Returns 2 – L/R Stereo Paired 1/4″ TRS Phone
Group Outputs 6 – 1/4″ TRS Phone AUX Outputs
Main Outputs L/R Balanced 3-pin XLR male
Monitor Outputs L/R 1/4″ TRS Phone
EQ Section
  • 100Hz, 18dB per octave
  • HF: 12kHz, +/-15dB, 2nd order shelving
  • Hi-Mid: 550Hz-13kHz, +/-15dB, Q=1
  • Lo-Mid: 80Hz-1.9kHz, +/-15dB, Q=1
  • LF: 80Hz, +/-15dB 2nd order shelving
Phantom Power +48 Volt
Power Supply Universal Mains input 85V-270V AC, 50Hz/60Hz
Power Consumption – less than 50W
Dimensions 41.4 x 6.5 x 19.8″ (1059 x 164 x 503mm)
Weight 50lbs (23kg)
Signal-to-Noise Ratio < -128dBu (150 Ohm source)
22Hz – 22kHz bandwidth, unweighted
Total Harmonic Distortion (THD) <0.007% @ 1kHz (XLR Input to Direct Output)
<0.008% @ 1kHz (XLR Input to Mix Output)
