Soundcraft Audio Mixer GB2R 16-Channel Rack-Mountable with GB-30 Preamps

Soundcraft

AED 7279.43 inc VAT.

In stock
Enquiry On Whatsapp
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: GB2R Categories: , Brand:

The Soundcraft GB2R-16 16-Channel Console offers cutting-edge audio mixing with 16 mono input channels, featuring balanced 1/4″ TRS phone and XLR microphone inputs, individual switchable +48V phantom power, and advanced GB-30 microphone preamplifiers and precision EQ on all mono channels, inspired by the acclaimed GB-series.

Description

Soundcraft GB2R-16 16-Channel Console

The Soundcraft GB2R-16 16-Channel Console is a versatile audio mixer built on the acclaimed GB-series technology. Ideal for both professional and amateur audio engineers, this mixer offers exceptional sound quality and advanced functionality. It is equipped with 16 mono input channels, GB-30 microphone preamplifiers, and a precision EQ section on all mono channels to ensure a high level of audio performance.

Key Features

  • Soundcraft GB Series Technology
  • 16 Mono Input Channels
  • Stereo and Mono Sum Output
  • Individually Switched Phantom Power
  • 6 Auxiliary Sends
  • Rotatable Connector Pod

Specifications

Specification Details
Total # Of Inputs 16-Channels
Mic/Line Inputs 16 Mono Balanced XLR Microphone, 16 Mono Balanced 1/4″ TRS Phone Line
Stereo Line Inputs No
In-Line Inputs/Returns No
AUX Sends 6-Total (4 Balanced XLR, 2 Balanced 1/4″ TRS Phone)
AUX Returns 2 Stereo L/R 1/4″ TRS Phone
Inserts 1/4″ TRS Phone on all mono inputs, mix output, and subgroup outputs
BUS (Group) Outputs Stereo Output Only
2 Trk Master I/O Mix Output – 2 Balanced XLR, Mono Output – 1 Balanced XLR
ALT I/O Direct Outputs (All Mono Channels) – 1/4″ TRS Phone
Monitor Outputs Stereo L/R 1/4″ TRS Phone
EQ Section High pass Filter – 100Hz, 18dB/Octave, HF – 13kHz, +/-15dB, Hi-Mid – 550Hz-13kHz, +/-15dB, Lo-Mid – 80Hz-1.9kHz, +/-15dB, LF – 80Hz, +/-15dB
Solo/Mute Mute, Mix, Subgroup and PFL on all channels
Channel Level Control 100mm Fader
Trim/Gain Control Rotary Controls
Phantom Power +48V
Metering Input Channels: Single LEDs, Signal Present & Peak | Outputs: 2 tri-color, 12-segment LEDs
Frequency Response 20Hz to 20kHz < 1dB
Dynamic Range Not Specified By Manufacturer
Signal-to-Noise Ratio -128dBu, Measured RMS, 22Hz to 22kHz Bandwidth
Total Harmonic Distortion (THD) <0.006%
Power Supply Internal PSU: 90V-240V AC, 50/60Hz Universal Input, Power Consumption: Less than 100W
Dimensions 17.36 x 8.20 x 21.05″ (441 x 208.42 x 534.79mm)
Weight Not Specified By Manufacturer
Package Weight 35 lb
Box Dimensions (LxWxH) 26 x 22.1 x 12.8″
