Soundcraft Vi5000 Digital Mixing Console 128 Inputs 96 kHz

Soundcraft

AED 175428.49 inc VAT.

In stock
Enquiry On Whatsapp
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: 5057292 Categories: , , Brand:

The Soundcraft Vi5000 is a standalone digital live mixing console featuring 24 faders, 8 assignable bus faders, 32 mono/stereo busses, an onboard MADI interface, up to 128 inputs, a 48 kHz sampling frequency (upgradeable to 96 kHz), and a high-quality audio path designed for professional live touring, installations, and corporate AV applications.

Description

Soundcraft Vi5000 Digital Mixing Console

The Soundcraft Vi5000 is a standalone digital live mixing console with robust features tailored for professional live touring, installations, and corporate AV applications. Equipped with 24 faders, 8 assignable bus faders, and 32 mono/stereo busses, this console offers superior control and flexibility. With an onboard MADI interface and the capacity to mix up to 128 inputs, the Vi5000 is designed to deliver high-quality sound with a 48 kHz sampling frequency, which can be upgraded to 96 kHz, ensuring a pristine audio path.

Engineers will appreciate the console’s intuitive workflow, providing direct access to all functions with maximum visibility. The integration of touchscreens and encoders reduces complexity, while the FaderGlow illuminated faders and Vistonics II touchscreen interfaces enhance usability. The compact design allows for dual engineer operation and remote control via the Soundcraft ViSi app.

Features

  • Ideal for live touring, installations, and corporate AV
  • Supports 128 inputs, 24 main faders plus 8 bus faders
  • 32 mono/stereo busses
  • 48 kHz sampling, upgradeable to 96 kHz
  • Advanced DSP processing
  • Vistonics and FaderGlow interfaces
  • Optional MADI and Dante connections
  • Automixing for corporate events
  • Follow Solo fader illumination

Specifications

Specification Details
Frequency Response Stagebox Mic Input to Line Output: 20 Hz to 20 kHz, +0/-1 dB
AES/EBU AES/EBU In to AES/EBU Out: 20 Hz to 20 kHz, +0/-0.2 dB
THD & Noise Various specifications, including 0.003% at 1 kHz for Mic In/Out
Input & Output Mic Inputs: +28 dBu Max, Line Inputs & Outputs: +22 dBu Max
Impedance Mic Inputs: 10 Kilohms, Line Outputs: <75 Ohms
Oscillator 20 Hz to 20 kHz, Pink/White Noise
CMRR Stagebox Mic Input: 80 dB @ 1 kHz
Sampling Frequency 48 kHz or 96 kHz
Latency <2 ms @ 48 kHz, <1 ms @ 96 kHz
Internal DSP Resolution 40-Bit Floating Point
Internal Clock Precision <±50 ppm
Clock Jitter Internal Clock: <±5 ns
External Sync BNC Wordclock
Equalization 20 Hz to 20 kHz, ±18 dB, variable Q settings
Metering Internal 20-Segment LED Bargraphs, 9-Segment Gain-Reduction Meters
Mains Voltage 90 to 264 VAC, 47 to 63 Hz, Auto-Ranging
Power Consumption 300 W
Operating Temperature 32 to 113°F / 0 to 45°C
Relative Humidity 0 to 90%, Non-Condensing
Storage Temperature -4 to 140°F / -20 to 60°C
