Soundcraft Vi3000 Digital Live Sound Console with Dante, 48 Mic Inputs 5042680

Soundcraft

AED 215911.98 inc VAT.

In stock
Enquiry On Whatsapp
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: 5042680 Categories: , , Brand:

The Soundcraft Vi3000 is a digital live sound console equipped with 36 faders, 48 premium mic preamps, 24 mono/stereo busses, onboard Dante interface, supporting up to 96 mixable inputs at a 48 kHz sampling frequency, providing a clear audio path for professional live performances, installations, and corporate AV needs.

Description

Soundcraft Vi3000 Digital Live Sound Console

The Soundcraft Vi3000 is a versatile digital live sound console designed to meet the highest standards of professional audio engineering. It is equipped with advanced features and robust performance capabilities, making it an ideal choice for live touring, installation, and corporate AV applications.

Intuitive Design

The console’s intuitive workflow ensures a seamless operation for sound engineers. With direct access to all functions and maximum visibility, it integrates touchscreens and encoders to streamline the control processes. The compact surface design is optimized for easy use, while FaderGlow illuminated faders provide clear visual feedback by displaying different colors based on function. The four Vistonics II touch screen interfaces allow for dual-user operation, enhancing collaboration during live performances.

Remote Control

The Soundcraft Vi3000 offers advanced remote control capabilities through the Soundcraft ViSi app, enabling engineers to make adjustments from an iPad. This feature is particularly useful for large venues, allowing on-the-fly changes during live events without being tied to the console.

Key Features

  • Ideal for Live Touring, Installations, and Corporate AV
  • 48 High-Quality Mic Inputs and 36 Faders
  • Onboard Dante Interface and MADI-Ready
  • 24 Mono/Stereo Busses for Flexible Routing
  • 48 kHz Sampling Frequency for Clear Audio

Technical Specifications

Specification Details
Frequency Response +0/-1 dB, 20 Hz to 20 kHz (Stagebox Mic Input to Line Output)
AES/EBU +0/-0.2 dB, 20 Hz to 20 kHz; Input Sample Rate: 32 to 108 kHz; Impedance: 110 Ohms
THD 22 Hz to 22 kHz
Mic Input < 0.003% at 1 kHz (Stagebox Mic In to Local Line Out at Min. Gain); Input Levels: +28 dBu Max
Line Input < 0.003% at 1 kHz; Input Levels: +22 dBu Max
Line Outputs +22 dBu Max; < 75 Ohms
Nominal Operating Level +4 dBu (-18 dBFS)
Analog Inputs > 10 Kilohms
Mic Input Noise (E.I.N.) < -126 dBu (150 Ohms Source)
Residual Noise -91 dBu (Stagebox Line Output, No Inputs Routed, Mix Fader at 0 dB)
CMRR 80 dB at 1 kHz
Sampling Frequency 48 kHz
Latency < 2 ms at 48 kHz (Stagebox Mic Input to Local Line Output)
Internal DSP Resolution 40-Bit Floating Point
Internal Clock Precision < ±50 ppm
Clock Jitter < ±2 ns
External Sync BNC Wordclock
Oscillator 20 Hz to 20 kHz, Pink/White Noise, Variable Level; Filters: HP at 80 Hz, 12 dB/Oct (Stagebox), HP at 20 Hz to 600 Hz, LP at 1 kHz to 20 kHz, 18 dB/Oct (Channel)
Equalization HF EQ: 20 Hz to 20 kHz, ±8 dB, Q=0.3 to 8.7 or Shelving; Hi-Mid, Lo-Mid, LF EQ: 20 Hz to 20 kHz, ±18 dB, Q=0.3 to 8.7
Metering 20-Segment LED Bargraphs; 9-Segment Gain-Reduction Meters with Peak Hold Variable from 0 to 2 s
Mains Voltage 90-264 VAC, 47/63 Hz, Auto-Ranging
Power Consumption 300 W
Operating Temperature 32 to 113°F / 0 to 45°C
Relative Humidity 0 to 90%, Non-Condensing, Ta=104°F / 40°C
Storage Temperature -4 to 140°F / -20 to 60°C
Dimensions 13.8 x 56.9 x 31.6″ / 351 x 1446 x 803 mm
Weight 119 lb / 54 kg
