Description
Explore Superior Audio with the ProWave X1000 Wireless Microphone System
The ProWave X1000 Wireless Microphone System offers premium sound quality and unmatched reliability, making it the ideal choice for both professional performers and avid audio enthusiasts. Crafted with rugged metal and cast aluminum housing, this microphone system is built to withstand the rigors of any performance environment, ensuring long-lasting durability and consistent operation.
Key Features
Category |
Details |
Construction |
Rugged metal, cast aluminium housing |
Frequency Range |
20 Hz to 20 kHz (microphone dependent) |
Dynamic Range |
Over 120 dB |
Encryption |
AES 256-bit |
Battery Runtime |
Up to 9 hours (AA), up to 10 hours (Shure SB900) |
Operating Range |
100 meters (330 feet) |
Charging |
External contacts for docked charging |
Display |
Backlit LCD with selectable display mode |
Connector |
4-pin male mini (TA4M) |
Antenna |
Detachable ¼ wave |
Power Output |
1 mW or 10 mW |
Product Specifications
Specification |
Details |
Mic Offset Range |
0 to 21 dB (in 3 dB steps) |
Battery Types |
Shure SB900A Rechargeable Li-Ion or AA batteries 1.5 V |
Battery Runtime @ 10 mW |
Shure SB900A: up to 10 hours, Alkaline: up to 9 hours |
Dimensions |
86 × 65 × 23 mm, H × W × D |
Weight |
138 g, without batteries |
Audio Input Connector |
4-pin male mini connector (TA4M) |
Audio Input Impedance |
1 MΩ |
Maximum Input Level |
1 kHz at 1% THD: 8.5 dBV (7.5 Vpp) |
Preamplifier Equivalent Input Noise |
System Gain Setting ≥ +20: -120 dBV, A-weighted, typical |
RF Connector |
SMA |
Antenna Type |
1/4 wave |
RF Impedance |
50 Ω |
Occupied Bandwidth |
< 200 kHz |
Modulation Type |
Shure proprietary digital |
RF Power |
1 mW or 10 mW |
