Loudspeakers

QSC WL3082-WH Ultra Compact Line Array Module – Dual 8″ Neodymium LF, 3″ Titanium Diaphragm, White

QSC

AED 16097.60 inc VAT.

The QSC WideLine-8 is a compact, high-output line array speaker system designed to meet the demands of venues with height or sightline restrictions and the need for excellent audio performance. Measuring less than 20 inches wide and 9 inches high, the WideLine-8 features a tri-amplified design with a pair of high-power, neodymium magnet 8-inch low-frequency drivers and a 3-inch diaphragm neodymium compression driver. The 140° multiple aperture diffraction waveguide ensures broad horizontal dispersion and minimized destructive interaction, delivering a superior stereo image and reducing the need for additional fill speakers.

In stock
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: WL3082-WH Categories: , , Brand:

Description

QSC WideLine-8 Ultra Compact Line Array Speaker

The QSC WideLine-8 redefines the standards for audio performance in compact line array systems. Designed for venues with height or sightline restrictions and for touring systems that need to minimize transportation costs without sacrificing sound quality, this speaker system integrates advanced technology into a portable size.

Despite its dimensions of less than 20 inches wide and 9 inches high, the WideLine-8 delivers full-size line array performance. It features high-power neodymium magnet drivers and a patented diffraction waveguide, ensuring broad coverage and high acoustic output without the need for supplemental speakers.

Features

  • Compact and lightweight design (20 in / 508 mm wide, 38 lb / 17.2 kg)
  • Maximum output of 133 dB SPL peak
  • Wide 140° horizontal coverage for broad stereo image
  • High-power 8-inch neodymium drivers with low-frequency extension to 62 Hz
  • 3-inch diaphragm compression driver with patented multiple diffraction aperture waveguide
  • Dual-purpose side-mounted vent ports that function as handles
  • Simple rigging system for arrays up to 12 units with 10:1 design factor
  • Support for ground stacking
  • Compatibility with EASE and EASE Focus software for acoustic modeling
  • Durable birch ply enclosure with black finish
  • Tri-amplified operation with DSP settings available on Q-SYS, SC-28, PLD, and CXD amplifiers
Key Specifications
Specification Details
Width 20 inches / 508 mm
Height 9 inches / 229 mm
Weight 38 lb / 17.2 kg
Peak SPL 133 dB
Coverage 140° horizontal
Low-Frequency Extension 62 Hz
Driver Type Neodymium magnet
Waveguide Patent Patent No. 7,177,437
Enclosure Material Birch ply
Color Black
Amplification Type Tri-amplified
