Midas PRO LCD Pushbutton Switches with Display and LED Backlight – Set of 8

AED 405.30 inc VAT.

PRO LCD SWITCH offers dynamic user interfaces with visual feedback and custom labeling for mixing console channels, buses, and groups, featuring a high-contrast FSTN LCD with 36×24 pixel resolution for clear viewing at wide angles, and a momentary switch action for reliable tactile feedback.

In stock

Request Quote

Estimated Delivery: 2–3 business days across the UAE
Free Shipping & Returns : On all orders over AED 1000

Guaranteed Safe And Secure Checkout

SKU: PRO LCD SWITCH Categories: AV, Electronics Audio Brand: Midas

Description

PRO LCD SWITCH

Experience the future of dynamic user interfaces with the PRO LCD SWITCH, designed for clear visual feedback and user-defined labeling of your mixing console’s channel, bus, and group selections. This innovative device features a high contrast FSTN LCD glass with 36 x 24 pixel resolution, offering unparalleled visibility from a wide vertical and horizontal viewing angle. The momentary switch action ensures reliable tactile response, crucial for mix engineers focused on live performance rather than their console.

Features

Momentary action pushbutton switch with tactile feedback
36 x 24 pixel resolution dot matrix graphic LCD display
RGB LED backlight for high visibility in all lighting conditions
FSTN LCD Glass for high contrast and wide viewing angle
8 distinct displayable LED colors
2 wire serial data interface with up to 1 MHz operation
Suitable replacement for Screenkeys* RGB24T LCD Switch in Midas XL8 and PRO SERIES consoles

Specifications

Specification	Details
Pixel Matrix	36 x 24
LED Backlighting Colors	Red, Green, Blue, Magenta, Cyan, White, Pink, Yellow
Operating Voltage	5 Volt DC (Nominal)
LCD Screen Size (L x W)	19.5 x 16.1mm (0.77 x 0.63″)
Pixel Field Size (L x W)	14.7 x 10.3mm (0.58 x 0.41″)
Maximum Data Rate	1 MHz
Operating Temperature Range	5 to 45 deg. C (41 to 113 deg. F)
Storage Temperature Range	-20 to 60 deg. C (-4 to 140 deg. F)
Dimensions	0.9 x 0.9 x 1.2″ (2.29 x 2.29 x 3.05cm)
