Midas M32C Digital Rack Mixer – 40 Input Channels, 25 Mix Buses

Midas M32C Digital Rackmount Mixer

The Midas M32C is a high-performance digital mixing core, ingeniously packed into a compact 1U form factor. Built with the robust combination of aluminium and steel, this mixer is designed for both live and installed sound applications. With 40 input channels and 25 mix buses, the M32C offers a plethora of connectivity options, including dual AES50 networking CAT5 connectors, ensuring up to 96 remote inputs and 48 output channels can be efficiently managed and processed.

Whether you pair it with the DL16 or DL32 Stage Boxes, the M32C is your solution for seamless audio management. It supports integrated personal monitor mixing and true high-speed digital audio networking, giving sound engineers unprecedented control over their audio landscapes. The inclusion of 8 DCA and 6 mute groups, along with 8 digital signal processing effects engines, allows for unmatched versatility in sound management.

Features

• 40-input channel, 25-bus, 1U rackmountable digital mixing core
• 25 time-aligned and phase-coherent mix buses
• Up to 96 inputs and 96 outputs via AES50 networking
• High-performance aluminium and steel construction
• 40-bit floating point digital signal processing
• 8 DCA and 6 mute groups
• 8 digital signal processing effects engines
• 32 x 32 channel USB 2.0 audio interface
• Built-in expansion port for additional audio interface cards
• MIDI In/Out for remote scene recall or external control
• Optional wireless remote control via Midas apps for iPhone and iPad
• Auto-ranging universal switch-mode power supply

Specifications
