Midas HUB4 Monitor System Hub with 4 PoE Ports, AES50 48/44.1 kHz, StageConnect, 16 Channel Analog Output

Midas HUB4 – Ultimate Stage Solution

The Midas HUB4 stands as the essential tool for your stage rack, expertly managing both analogue and digital outputs for various applications. With the capability to supply up to four DP48 personal monitor mixers via PoE (Power over Ethernet) and facilitating 48 channels of 24-bit / 48 kHz audio, the HUB4 ensures seamless performance. It also efficiently gathers 48 channels of upstream audio, forwarding it to the FOH console from stage boxes connected to the AES50-B (THRU) Port or 8 return channels from each of Ports 1-4.

Key Features

• Acts as a personal monitoring system hub with PoE remote powering for up to 4 DP48 personal mixers and stage boxes.
• Includes AES50 IN and THRU ports for cascading hubs or stage boxes, providing 48 bidirectional channels at 48 or 44.1 kHz.
• Equipped with 16 balanced analogue outputs for transmitting personal stereo mixes to IEM transmitters in the side rack.
• Supports channel naming and group assignments distribution from compatible M32 consoles.
• Allows connection and powering of Midas DL8 Stage Boxes from ports 1-4.
• Enables personal mix outputs monitoring via AES50 upstream to connected consoles.
• Facilitates remote control forwarding of a DP48 personal mixer from another DP48.
• Presents front panel buttons for directing signals to analogue output groups 1-4, StageConnect, and AES50-A upstream.
• Includes a StageConnect output with phantom power for connecting other StageConnect devices, sharing 32-channel audio, uncompressed PCM, 24-bit at 44.1/48 kHz with sub-millisecond latency over standard XLR microphone or DMX cable.
• Supports remote operation via shielded CAT5e cable up to 260 ft / 80 m length recommended.
• Features robust Neutrik etherCON* AES50 network ports and a rugged 1U chassis ideal for durable portable applications.
• Utilizes an auto-ranging universal switch-mode power supply.

Specifications
