Lab Gruppen LUCIA 120/1-70 Compact 120W Mono 70V Amplifier

Lab Gruppen

AED 1,783.95 inc VAT.

In stock
Enquiry On Whatsapp
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: LUCIA 120/1-70 Category: Brand:

The LUCIA 120/1-70 combines 120 W of decentralized power with easy installation in a compact, Energy Star compliant amplifier. Featuring Lab Gruppen’s cutting-edge digital and firmware-controlled front end, it delivers superior audio performance, flexibility, and reliability, making it an ideal solution for AV applications needing outstanding performance without the need for a centralized equipment room.

Description

Product Overview

The LUCIA 120/1-70 is a compact and energy-efficient amplifier designed for high impedance speaker systems. This cutting-edge amplifier is part of Lab Gruppen’s LUCIA series, offering unprecedented flexibility and superior audio performance in AV system design.

Key Features

  • 120 W mono amplifier for 70 V distribution lines
  • On-board DSP with advanced loudspeaker processing
  • Automatic Dynamic Loudness Contouring for optimal performance at any output level
  • Energy Star certification for low operating costs and high energy efficiency
  • USB connection for firmware updates and configuration
  • Compact design with half-rack, 1U chassis
  • Configurable GPIO port for versatile remote control
  • Comprehensive circuit protection for fail-safe operation

Specifications

Category Specification Details
General Number of amplifier channels 1
Max total output 120 W
Max output voltage 100 Vpeak
Max output current 3.5 Arms
Performance 70 V 120 W
100 V 60 W
16 ohms 120 W
Signal to Noise Ratio >100 dBA
Gain, Sensitivity, and Limiters VPL 100 Vpeak
Sensitivity, balanced input 4 dBu / 1.23 Vrms
Sensitivity, RCA input -2 dBu / 0.62 Vrms
Connectors and Buttons Input connectors 3 – pin detachable screw terminals, electronically balanced
Output connector 2 – pin detachable screw terminal
USB For firmware update and configuration
Power Nominal voltage 100 – 240 VAC
Operating voltage 85 – 265 VAC
Standby consumption <1 W
Dimensions Width 216 mm (8.5”)
Height 44 mm (1 U)
Depth 280 mm (11”)
Weight 1.9 kg (4.2 lbs)
Certifications Approvals CE, CSA, CCC, PSE, FCC, Energy Star
