Description
High power density, competitive cost, and power consumption efficiency make the IPX 2400 the ideal compact yet powerful amp solution whether it’s for permanent installations, portable corporate AV systems, or live PA setups.
Features
- Compact 2,400 Watt, 2-channel amplifier with DSP control for touring applications
- Low mains current draw with proven IDEEA technology for power conservation
- Highly advanced DSP with 40 real-time multi-slope Parametric EQs
- 100 user presets for system configuration and setup
- Networked control via touchscreen user interface
- AES3 and analogue inputs with redundant failover
- Renowned Speaker Protect Limiter (maxSPL) for optimal speaker match and protection
- 4-channel input mixer for multi-input mixing and switching
- Backlit display with navigation buttons and encoder for front panel setup
- Horizontal output VU meters on display in operating mode
- Binding post and Neutrik speakON connectors
- Universal power supply supports 100 – 240 V at 50 or 60 Hz
- Fast network setup with auto-discovery and identification of amplifiers
Specifications
Maximum Output Power
| 2 Ω per channel, stereo |
800 W |
| 4 Ω per channel, stereo |
1200 W |
| 8 Ω per channel, stereo |
600 W |
Controls
| Front |
Power switch, DSP section rotary push-encoder, Buttons for Menu, Back, Mute (per channel) |
System
| Number of channels |
2 |
| Output voltage |
100 V peak / 70 Vrms / 39.2 dBu |
| Input sensitivity for maximum output voltage |
6 dBu |
| Output current |
20 Arms |
| Output circuit type |
Class-D |
| THD+N |
< 0.1%, 20 Hz – 20 kHz @ 1 W< 0.05% @ 1 kHz, 1 dB below clip |
| Output noise |
-65 dBu, A-weighted |
| Signal-to-noise |
> 104 dB |
| Channel crosstalk |
> 80 dB @ 1 kHz |
| Frequency response |
10 Hz to 20 kHz, +0.5/-1 dB 5 Hz to 40 kHz, -3 dB |
| Common mode rejection (CMR) |
> 50 dB |
| Gain (all DSP controls set to 0 dB) |
33 dB |
Indicators
| Power |
Red LED |
| Limit, per channel |
Red LED |
| Signal / mute, per channel |
Green/Red LED |
