Lab Gruppen E 12:2 1200W 2-Channel Installation Amplifier

Lab Gruppen

AED 5662.65 inc VAT.

The E 12:2 showcases advanced smart green credentials with an emphasis on cost-effective ownership, featuring low current draw during operation, reduced power consumption during idle periods, and adherence to Energy Star certification standards, all while maintaining high output levels and the exceptional sonic performance expected from Lab Gruppen products.

In stock
Request Quote
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: E 12:2 Categories: , Brand:

Description

The E 12:2 Amplifier

The E 12:2 is designed with smart green credentials to deliver a low lifetime cost of ownership.
It maintains minimal current draw during high output levels and reduces power consumption during non-operational cycles.
This Energy Star certified amplifier harnesses superior Lab Gruppen sonic performance and robust power output while meeting rigorous efficiency standards.

Features

  • 1200 W amplifier with 2 flexible output channels in a 1 rack unit form factor
  • Energy efficient with Energy Star certification for low lifetime running costs
  • Flexible IntelliDrive for 2 x 600 W at constant voltage 70 V or low impedance (2, 4, and 8 Ohms)
  • Asymmetric channel loading to maximize system efficiency
  • Low power consumption and minimized heat generation
  • IDEEA output stage with state-of-the-art Class-D amplifier technology
  • Comprehensive fail-safe circuit protection
  • Auto-standby and auto-power-on functions
  • Rail Sense Limiter (RSL) to reduce signal clipping
  • Built-in 50 Hz high pass filter selectable per channel
  • Per-channel attenuation knob and signal LED on rear panel
  • Efficient cooling with temperature-controlled fan
  • Aluminum front panel with power and temperature LEDs
  • GPIO connector with power control and indication
  • Balanced analog inputs and outputs on detachable screw terminals

Specifications

Specification Details
Number of amplifier channels 2
Max total output all channels driven 1200 W
Peak output voltage per channel 100 V / 70 Vrms
Max. output current 18 Arms

Max output power (all channels driven)

Load Power Output
2 ohms 600 W
4 ohms 600 W
8 ohms 600 W (70 V mode)
16 ohms 310 W (70 V mode)
70 V 600 W
100 V 600 W (100 V load tapped at 1200 W)

Performance

Specification Details
THD 20 Hz – 20 kHz at 1 W <0.1%
THD at 1 kHz and 1 dB below clipping <0.05%
Signal to Noise Ratio >112 dBA
Channel separation (Crosstalk) at 1 kHz >70 dB
Frequency Response 2 Hz – 40 kHz
Input impedance 20 kOhm
Common Mode Rejection (CMR) 50 dB
Output impedance 25 mOhm

Dimensions & Weight

Specification Details
Dimensions W: 483 mm (19”), H: 44 mm (1 U), D: 276 mm (10.9”)
Weight 4.2 kg (9.3 lbs)

Approvals

Specification Details
Approvals CE, RoHS, WEEE, UL (UL 60065), CSA C22.2 NO. 60065, FCC Part 15 Subpart B Class A, PSE, CCC Energy Star
