Lab Gruppen D 80:4L Amplifier – 8000W, 4 Channels, Lake DSP, Digital Audio Networking

Lab Gruppen

AED 31649.10 inc VAT.

The D 80:4L delivers 8000 W of power, featuring Lake DSP, DANTE digital audio networking, and advanced system integrity monitoring. Built on the reliable and high-performance amplifier technologies of our PLM Series, it promises the same robustness and sound quality proven in rigorous concert tours and large-scale installations.

In stock
Request Quote
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: D 80:4L Categories: , Brand:

Description

D 80:4L Audio Amplifier with Lake DSP and DANTE

The D 80:4L combines 8000 W of flexible power with the latest Lake DSP, DANTE digital audio networking, and advanced system integrity monitoring. Based on the robust PLM Series amplifier technologies, the D 80:4L is built for reliability and superior sonic performance in demanding environments such as concert tours and large-scale installations.

Key Features

  • 8,000 Watt amplifier with 4 flexible output channels and up to 5,900 Watts channel output
  • Lake digital signal processing for unparalleled loudspeaker management and system control
  • Integrated 8×8 channels of dual redundant Dante digital audio networking with AES67 support
  • Proven and reliable Class-TD output stage with proprietary Intercooler high-efficiency cooling system
  • Rational Power Management provides total flexibility to allocate available power across all 4 output channels
  • Dedicated on-board surveillance and load monitoring for mass notification applications

Specifications

Specification Details
Processing / Network Lake / Dante
Number of amplifier channels 4
Total burst power all channels (share among channels with RPM) 8000 W
Max output power (2 ohms) 2000 W
Max output power (4 ohms) 2000 W
Peak output voltage 194 V
Max. output current 67 A
THD + N at 1 kHz and 1 dB below clipping < 0.04 %
Frequency response +/- 0.05 dB (20 Hz – 20 kHz)
Weight 14.5 kg (32 lbs)
Dimensions W: 483 mm (19″), H: 88 mm (2 U), D: 424 mm (16″)
Approvals CE, ETL(ANSI/UL, CSA), PSE, RCM
