Lab Gruppen C 68:4 4-Channel 6800W Amplifier with NomadLink Network Monitoring

Lab Gruppen

AED 19530 inc VAT.

The C 68:4 amplifier delivers 4 × 1700 W at 4 ohms, providing ample power for demanding installed sound applications. Housed in a compact 2U chassis, it sets a new standard for high power in installation-specific amplifiers.

In stock
Request Quote
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: C 68:4 Categories: , Brand:

Description

C 68:4 High-Power Audio Amplifier

The C 68:4 is a premier 4-channel amplifier designed to deliver exceptional power and control for demanding sound installations. It provides 4 x 1700 W at 4 ohms, ensuring high performance and reliability in a space-efficient 2U chassis. Ideal for a range of professional audio applications, this amplifier sets a new benchmark for power and durability.

Key Features

  • 6,800 Watt, 4-channel amplifier with up to 1,700 Watts output per channel and NomadLink network for monitoring and control
  • Selectable gain plus scalable Voltage Peak Limiter (VPL) and bridge-mode operation for custom configuration
  • Proven and reliable Class-TD output stage for superior sound quality
  • Regulated Switch Mode Power Supply (R.SMPS) ensures consistent power delivery
  • Comprehensive protection scheme including current, voltage, DC, temperature, short circuit, and open load warnings
  • Efficient Intercooler copper cooling system for optimal heat dissipation

Specifications

Specification Details
Number of amplifier channels 4
Peak total output all channels driven 6800 W
Peak output voltage per channel 141 V
Max output current per channel 24.5 Arms
16 ohms output power 650 W
8 ohms output power 1200 W
4 ohms output power 1700 W
2 ohms output power 1200 W
Hi-Z power (70V/100V) 1600 W
THD (20 Hz – 20 kHz at 1 W) < 0.1%
Signal to Noise Ratio > 112 dBA
Frequency response 6.8 Hz – 34 kHz (+0 / -3 dB)
Input impedance 20 kOhm
Dimensions (W x H x D) 483 mm x 88 mm x 343 mm
Weight 12 kg
Finish Black painted steel chassis with gray painted steel front
Approvals CE, ANSI/UL 60065 (ETL), CSA C22.2 NO. 60065, FCC
