Klark Teknik DN9610 Dual Port AES50 Repeater, 100m Range, 96 kHz Capacity

DN9610 AES50 Repeater

The DN9610 offers an affordable solution to the 100-meter limit imposed by Ethernet and CAT5 cabling in AES50 networks. With its compact form, the DN9610 can be conveniently placed to extend network connections, requiring only a mains power source.

Key Features

• Extends two independent AES50 connections by up to 100 m with CAT5 cable
• High channel capacity – 48 channels @ 96 kHz or 96 channels @ 48 kHz bidirectional operation
• Supports dual-redundant AES50 networks (X and Y connections)
• Rugged locking Neutrik etherCON connectors for AES50 connections
• Status indicator LEDs for each AES50 port
• Dual-redundant power supply inputs with locking Switchcraft connectors
• External auto-ranging universal switch-mode power supply adapter
• Durable aluminium casing with a stackable protective silicone rubber sleeve
• Compact and robust design
