Description
Building on KLARK TEKNIK’s storied legacy of highest-quality direct injection devices, the DI 10A PRO DI ACTIVE offers high headroom, dynamic response, and sonic clarity. The DI 10A is ideal for interfacing keyboards, samplers, and other electronic musical instruments to mixing consoles, faithfully reproducing the character of electric and acoustic instruments. It is powered by +48 V phantom power with a 9V battery backup. Equipped with a switchable input attenuator, the DI 10A accommodates instruments, line, and loudspeaker level signals while providing extended dynamic range.
Features
- Active DI Box for general purpose and multimedia applications
- Custom-built Midas transformer for highest signal integrity
- High headroom design offers superior sound quality
- Powered from console +48 V phantom or internal battery (not included)
- Automatic switchover to battery if phantom power fails
- Matches the level and impedance with unity gain without loading the source
- Switchable input attenuation for guitar, line, and speaker levels
- High quality Neutrik* XLR and high impedance 1/4″ TRS connectors
- Earth Lift switch eliminates ground loop problems
- Fully transformer-isolated design ensures electrical separation
- Ultra-low noise and ultra-linear system for highest signal integrity
- Aluminium extrusion casing with protective rubber corners
- Compact and rugged design
Specifications
Audio Connections
| Input |
1 x XLR, balanced, 1 x 1/4″ TS, unbalanced |
| Input Impedance |
> 250 kΩ |
| Thru |
1 x 1/4″ TS, unbalanced |
| Output |
1 x XLR, balanced |
| Load Impedance |
> 600 Ω |
| Maximum Input level |
+10 / +30 / +50 dBu |
System
| Frequency Response |
10 Hz to 90 kHz, ±3 dB |
| THD+N |
< 0.02 % @ 1 kHz, 0 dBu |
| Noise Level |
< -112 dBu |
| PAD Switch |
0 / -20 / -40 dB |
Power Supply
| Phantom power |
18 V DC to 48 V DC |
| Battery |
9 V Blockcell 6LR61 |
Dimension / Weight
| Dimensions (W x D x H) |
118 x 120 x 64 mm (4.6 x 4.7 x 2.5″) |
| Weight |
0.56 kg (1.2 lbs) |
