JBL SCS 12 Ceiling Passive Surround Loudspeaker

AED 4925.45 inc VAT.

The JBL SCS 12 is a passive, two-way ceiling surround speaker for immersive cinema systems, featuring a coaxial 12″ woofer and 1″ compression driver with a frequency range of 55 Hz to 20 kHz. It utilizes a 400W peak amplifier, achieving a peak SPL of 128 dB. The speaker is built for reliability with a Kevlar-reinforced cone, high-temperature voice coil, and thick ABS and fiberglass enclosure. A U-type mounting bracket is included.

In stock

Request Quote

Estimated Delivery: 2–3 business days across the UAE
Free Shipping & Returns : On all orders over AED 1000

Guaranteed Safe And Secure Checkout

Description

JBL SCS 12 Cinema Ceiling Surround Speaker

The JBL SCS 12 is a two-way passive cinema ceiling surround speaker, perfect for immersive sound systems. Designed to deliver exceptional audio clarity, this speaker features coaxial 12″ woofers with Kevlar-reinforced cones and a 1″ compression driver. With a peak SPL of 128 dB, it ensures high-fidelity sound coverage across a frequency range of 55 Hz to 20 kHz.

Key Features

Coaxial 12″ woofer with Kevlar-reinforced cone and 3″ voice coil
1″ high-frequency compression driver with patented design
Frequency response of 70 Hz to 20 kHz
High-power passive crossover network for optimized performance
Durable ABS and fiberglass enclosure

Specifications

Specification	Details
Active or Passive	Passive
Speaker Configuration	2-Way
Power Handling	250 W RMS (for 100 hours), 400 W RMS (for 2 hours)
Impedance	5.7 to 8 Ohms (Minimum, Nominal)
Frequency Range	55 Hz to 20 kHz
Maximum SPL	128 dB
Sensitivity	96 dB SPL (Half-Space)
Coverage Angle	100° H x 100° V
Crossover	1.8 kHz, 12/18 dB/Octave
Mounting Options	2 x M10 Bracket Point (Each Side), 1 x M6 Fly Point (Rear)
Construction Material	ABS, Stainless Steel Grille
Dimensions	15.8 x 15.8 x 17.5″ / 401.32 x 401.32 x 444.5 mm
Weight	31.0 lb / 14.1 kg
