JBL AWC129 All-Weather Coaxial Loudspeaker

The black JBL AWC129 is a single all-weather passive coaxial loudspeaker designed for high-output, full-range sound reinforcement in various indoor and outdoor environments such as sports facilities, stadiums, fairgrounds, cruise ships, and background music/paging systems.

Capable of up to 400W long-term power handling, it features a 12″ Kevlar-reinforced woofer and a 1″ fluid-cooled high-frequency driver to produce a high maximum peak SPL of 128 dB and a wide frequency response of 55 Hz to 20 kHz (-10 dB). The coaxial speaker configuration provides a 90 by 90° dispersion pattern for consistent coverage.

The paintable ABS enclosure boasts an IP56 rating for effective weather resistance and a sturdy steel grille backed with open-cell foam for additional protection. An integrated multi-tap transformer—configurable via a rear-panel tap selector—allows operation in 70/100V systems or 8-ohm low-impedance setups. A color-matched U-bracket is included for ease of installation.

Key Features

• Highly weather-resistant IP56 rating
• Coaxial speaker design with 12″ Kevlar-reinforced woofer and 1″ fluid-cooled high-frequency compression driver
• 400W power handling with high sensitivity providing high SPL capability
• Consistent 90 x 90° broadband pattern control
• High-slope passive crossover network for constant coverage and natural midrange
• Minimum audibility SonicGuard high-frequency overload protection
• 55 Hz to 20 kHz frequency range (-10 dB), 80 Hz to 20 kHz frequency response (±3 dB)
• Built-in 200W 70/100V multi-tap transformer or direct 8-ohm low-impedance transformer bypass
• Paintable enclosure constructed of thick ABS and fiberglass
• Heavy-duty, weather-capable U-type mounting bracket included
