Digital Signal Processors (DSPs)

JBL Cinema CPI2000 Surround Sound Processor (2 RU)

JBL Cinema

AED 13298.79 inc VAT.

The JBL 2 RU Cinema Processor is designed to enhance audio and manage volume for cinema surround sound systems. It includes DSP processing, room EQ tuning, volume control, and system fault detection, configurable via specialized GUI software. The unit offers four inputs (analog, digital, non-sync, and mono mic) and multiple analog outputs including 10 x 15-pin and 25-pin connectors for various passive to tri-amp setups. With redundancy, it ensures continuous audio output during power failures by directly bypassing the CPi2000 system.

In stock
Request Quote
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: CPI2000 Categories: , , Brand:

Description

JBL Cinema Processor 2 RU

The Cinema Processor 2 RU from JBL is engineered to enhance audio and control volume for surround sound systems in cinema settings. This unit features DSP processing, room EQ tuning, and system fault detection, and can be configured using intuitive GUI software. Supporting both analog and digital inputs, this processor is versatile in its applications with a total of four inputs including non-sync and mono microphone options. The processor includes multiple output connections ensuring seamless integration with various audio systems, even providing a redundant output for backup in the event of power failure.

Key Features

  • Accepts both analog and digital inputs
  • Non-sync input for stereo music playback from CD/DVD players
  • Microphone input for calibration or voice announcements
  • USB port for import/export of configuration files
  • LAN port for GUI control and firmware updates
  • Multiple analog output configurations supporting up to 7.1 channels
  • Redundant output for audio signal continuity
  • Universal power input and redundant DC power input
  • Large front panel LCD for status monitoring
  • Quick-access controls for volume and source selection
  • 1/3 octave GEQ for room tuning via GUI software
  • Variable crossover presets for diverse speaker setups
  • Supports TMS communication for remote control capabilities

Specifications

Specification Details
Connectors 1 x 25-Pin Female, Balanced Digital Input
1 x 25-Pin Female, Balanced/Unbalanced Analog Input
1 x 3-Pin XLR Female, Balanced/Unbalanced Microphone Input
1 x RCA L/R Non-Sync, Stereo Music Input
1 x 25-Pin Male, Balanced/Unbalanced Analog Output
1 x 25-Pin Male, Balanced/Unbalanced Redundant Output

10 x 15-Pin Female, Balanced/Unbalanced Analog Output
1 x USB Type-A Port
1 x RJ45 LAN Port
1 x IEC, 100-240 V Power Input
1 x 4-Pin XLR Female, Backup 12 VDC, 2 A Power Input
Impedance Digital Input: 110 Ohms
Analog Input: 50 Kilohms Balanced, 25 Kilohms Unbalanced
Microphone Input: 660 Ohms
Non-Sync Music Input: 25 Kilohms
Analog/Redundant Output: 30 Ohms
Input Level Digital Input: 0.5 – 10 Vpp
Analog Input: 14.2 dBu Max.
Non-Sync Music Input & Analog/Redundant Output: 14.2 dBu
Total Gain Microphone Input: 40 dB
Mic Input Noise (E.I.N.) > 113 dB, 20 kHz Bandwidth
Frequency Response 20 Hz to 20 kHz, Ref 1 kHz ±1 dB
THD + N < 0.01%, 20 Hz to 20 kHz
Dynamic Range > 102 dB
Power AC Input: 100-240 VAC, 50/60 Hz
DC Input: 12 VDC, 2 A
Rack Space 2 RU
Dimensions 18.98 x 3.46 x 9.09″ / 482 x 88 x 231 mm
Weight 8.82 lb / 4 kg
