Loudspeakers

JBL Cinema Three-Way ScreenArray Speaker 4732-M/HF-T with 107 dB Sensitivity

JBL Cinema

AED 13853.11 inc VAT.

In stock
Enquiry On Whatsapp
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: 4732-M/HFD Categories: , , Brand:

The 4732 ScreenArray is a sophisticated three-way sound system designed for optimal film audio reproduction in medium to large cinema settings, delivering enhanced auditory experiences with precision and clarity.

Description

Key Features

The 4732 ScreenArray is designed for precise film sound reproduction in medium to large cinema environments, offering a true three-way system for optimal sound performance.

  • Three-way ScreenArray design ensuring maximum output with optimal coverage and minimal distortion
  • Triamplified or Biamplified operational capabilities
  • Certified for THX applications (4732T)
  • Ships fully assembled for easy installation
  • Advanced Aperture Waveguide technology providing ultra-low distortion and uniform frequency response
  • SSC Screen Spreading Compensation technology
  • Focused Coverage Technology for precise audio distribution
  • Flat-front waveguide design suitable for baffle wall installation and shallow profile for minimal space requirements
Specification Details
Frequency Range 30 Hz – 20 kHz
Frequency Response 40 Hz – 19 kHz (±3 dB)
System Sensitivity 107 dB, 2.83V @ 1m (3.3 ft)
Rated Maximum SPL 130 dB @ 1m (3.3 ft), 136 dB peak
System Input Power Rating LF: 800 W, M/HF: 200 W, 4732-T HF: 85 W
Horizontal Coverage Angle 90° (-6 dB)
Vertical Coverage Angle 20° up, 30° down (-6 dB)
Directivity Factor (Q) 10.0
Directivity Index (DI) 10 dB
Crossover Frequencies 4732: 250 Hz, 4732-T: 1.2 kHz
Dimensions (H x W x D) 2427 x 762 x 450 mm (95.6 x 30 x 17.75 in)
Net Weight 84.4 kg (186 lbs)
Shipping Weight 103.5 kg (228 lbs)
