JBL C222HP-TOP 1500W Two-Way ScreenArray Cinema Loudspeaker

JBL Cinema

AED 9179.11 inc VAT.

The C222HP Two-Way ScreenArray Cinema Loudspeaker from JBL features Dual Dissimilar Arraying and Acoustic Aperture Technology, offering uniform coverage and accurate sound in a compact design suitable for small to mid-sized cinemas, multiplexes, and dubbing stages. Trusted by top movie studios, this loudspeaker ensures a captivating audio experience for all audience members.

In stock
Request Quote
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: C222HP-TOP Categories: , , Brand:

Description

JBL C222HP Two-Way ScreenArray Cinema Loudspeaker

The JBL C222HP Two-Way ScreenArray Cinema Loudspeaker is designed to deliver exceptional audio quality in small and mid-sized cinema environments, as well as studios and dubbing stages. With the latest advancements in audio technology, this loudspeaker offers outstanding performance, ensuring every audience member enjoys a captivating and authentic sound experience.

Key Features

  • Next-generation two-way ScreenArray® design for maximum output, enhanced coverage, and minimal distortion.
  • Patent-pending Dual Dissimilar Arraying Technology for optimized coverage in raked seating areas and extended HF output power.
  • Acoustic Aperture Technology for low distortion, high sensitivity, and improved mid-range performance.
  • Compact 14″ deep footprint, ideal for installations with space constraints.
  • Maximum throw distance of 35 meters (115 feet).

Specifications

Specification Details
Frequency Response (-3 dB) 44Hz – 18kHz
Frequency Response (-6 dB) 40Hz – 20kHz
Frequency Response (-10 dB) 36Hz – 20kHz
Max Continuous SPL 135 dB
Horizontal Coverage (-6 dB) 100° @ 4kHz
Vertical Coverage (-6 dB) Asymmetrical 600 (+25, -45 @ 4kHz)
LF Nominal Impedance 4Ω
HF Nominal Impedance 8Ω
LF Minimum Impedance 3.15Ω @ 140Hz
HF Minimum Impedance 3.89Ω @ 9kHz
LF Power Handling (2Hr AES Rating) 1200W
LF Power Rating (100Hr AES Rating) 720W
HF Power Handling (2Hr AES Rating) 85W
LF Sensitivity 103 dB SPL @ 2.83V
HF Sensitivity 112 dB SPL @ 2.83V
Low Frequency 2 x 2275H-BK
High Frequency 2 x 2515XP-J
Maximum Throw Distance 35 meters (115 feet)
Dimensions (H x W x D) 59 x 33.75 x 14 inches (149.8 x 85.73 x 35.56 cm)
Input Connectors Screw Terminal Barrier Strip
