Electro-Voice ZX-4 15-Inch 400W 2-Way Full Range Speaker

The Electro-Voice ZX4 is a black 15″ 2-way 400W passive loudspeaker designed for versatile sound reinforcement in both portable and installed settings like churches, clubs, concert halls, and stadiums. Featuring a 15″ woofer, a 1″ titanium-diaphragm compression driver, and a 90 x 50° horn, it provides a 60 Hz to 20 kHz frequency response with 400W continuous power handling (1600W peak). Ideal for use as a main PA or floor monitor.
- Estimated Delivery: 2–3 business days across the UAE
- Free Shipping & Returns : On all orders over AED 1000
Description
Electro-Voice ZX4 15″ 2-Way 400W Passive Loudspeaker
The black Electro-Voice ZX4 is a versatile and powerful 15-inch 2-way passive loudspeaker designed to deliver exceptional audio performance in a variety of settings, including houses of worship, clubs, concert venues, and stadiums. Whether you need a reliable main PA system or a robust floor monitor for live performances, the ZX4 is engineered to meet your requirements with its full-range sound reinforcement capabilities.
Featuring a 15-inch woofer and a 1-inch titanium diaphragm high-frequency compression driver, the ZX4 offers a wide frequency response from 60 Hz to 20 kHz and can handle 400W of continuous power (1600W peak). The high-frequency driver is mounted in a 90° x 50° horn, ensuring clear and controlled sound coverage.
Key Features
- 15″ EVS15-SF woofer for deep, accurate bass
- DH3 compression driver with titanium diaphragm for clear highs
- 90° x 50° horn for controlled coverage
- High sensitivity of 100 dB and maximum SPL of 132 dB
- Lightweight, rugged polypropylene enclosure
- Integral pole mount for easy positioning on stands
- Multiple mounting options for permanent installations
Specifications
Specification | Details |
---|---|
Configuration | Passive 2-Way |
Enclosure Type | Bass-Reflex Loudspeaker/Floor Monitor |
Total Power Capacity | 400 W RMS / 1600 W Peak |
System Impedance | 8 Ohms (Nominal) |
Frequency Range | 42 Hz to 20 kHz (-10 dB) |
Frequency Response | 60 Hz to 20 kHz (-3 dB) |
Maximum SPL | 132 dB |
HF Driver | 1 x Horn-Loaded Titanium Compression Driver with 1″ (25.4 mm) Throat |
LF Driver | 1 x 15″ (38 cm) Woofer |
Protections | Transducer Overdrive |
Audio I/O | 2 x speakON NL4 Male Unbalanced Speaker Input (Lockable) |
Crossover | 1.5 kHz |
Mounting |
1 x Pole Socket (Bottom) 2 x Fly Point (Top) 2 x Fly Point (Side) 4 x Fly Point (Bottom) 3 x Bracket Point |
Handles | 1 x Side |
Construction Material | Metal Grille, Polypropylene |
Dimensions | 27.3 x 17.6 x 16.2″ (692 x 446 x 411 mm) |
Weight | 44.5 lb (20.2 kg) |
