Electro-Voice TX-1181 18-Inch 500W Subwoofer

Electro-Voice

AED 4752 inc VAT.

The TX2152 features a high output 2-inch titanium compression driver with a Constant Directivity 60° x 40° horn for optimal pattern control, dual SMX2151 15-inch woofers with low distortion and high intelligibility, and a steep 36 dB/octave crossover. Its robust, coated trapezoidal enclosure includes handles and multiple mounting points for versatile installation, a strong, dent-resistant grille, and concealed input connectors for space-efficient placement.

In stock
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: TX-1181 Categories: , , Brand:

Description

TX2152 High-Performance Loudspeaker

The TX2152 is engineered for exceptional audio reproduction in a variety of settings. Utilizing the advanced ND2 neodymium 2-inch titanium compression driver paired with a 60° x 40° constant directivity horn, this loudspeaker offers outstanding pattern control for medium throw applications. Dual SMX2151 15-inch woofers with optimized magnet structures ensure low distortion and high intelligibility, even at elevated sound pressure levels.

The crossover features steep 36 dB/octave slopes and equalization for a smooth vocal response, coupled with a protection circuit to ensure long-term reliability. Designed for versatility, the TX2152 is perfect for both portable and fixed installations, housed in a rugged plywood and MDF trapezoidal enclosure coated with EVCoat for durability. The robust grille is dent-resistant and includes a rotatable logo, while four-way handles provide multiple carrying options.

This loudspeaker can be suspended using six M8 or six 3/8-inch threaded points and can be positioned close to walls thanks to its recessed input panel with dual NL4 connectors. Identical in width and height to the TX2181, the TX2152 offers a cohesive look when stacked and optimizes storage and transport efficiency.

Technical Specifications

Specification Details
Frequency Response (-3 dB) 55 Hz – 13 kHz
Frequency Range (-10 dB) 50 Hz – 18 kHz
Recommended High-Pass Frequency 40 Hz
Axial Sensitivity 103 dB (1W/1m)
Maximum Calculated SPL 139 dB
Horizontal Coverage 60°
Vertical Coverage 40°
Power Handling 1000 W Continuous, 4000 W Peak
LF Transducer (2) SMX2151, 15 in (381 mm) Drivers
HF Transducer ND2-8, 2 in (51 mm) Diaphragm Compression Driver
Crossover Frequency 1750 Hz
Nominal Impedance 4 Ohms
Minimum Impedance 3.1 Ohms
Connectors (2) Neutrik Speakon NL4
Enclosure Plywood and MDF with EVCoat
Grille 16 GA Steel, Black Powdercoat, Rotatable Logo
Suspension (6) M8 or (6) 3/8-inch Threaded Points
Dimensions (H x W x D) 45.4 in x 20.0 in x 18.5 in (1154 mm x 508 mm x 471 mm)
Net Weight 94.3 lb (42.8 kg)
Shipping Weight 105.8 lb (48.0 kg)
