Crown Audio CDi 4|600BL 4-Channel Power Amplifier with BLU Link (600W)

AED 12286.55 inc VAT.

The Crown Audio CDi 4|600 is a 600W, 4-channel DriveCore Series power amplifier featuring high-performance and reliability, ideal for medium-sized installations such as cinemas, houses of worship, and bars. It includes advanced DSP, network control, 256-channel BLU Link capability, and is optimized with JBL speaker tunings for quick setup. The amplifier supports 100Vrms speaker loads and offers configuration via HARMAN HiQnet Audio Architect software.

In stock

Request Quote

Estimated Delivery: 2–3 business days across the UAE
Free Shipping & Returns : On all orders over AED 1000

Guaranteed Safe And Secure Checkout

Description

Crown Audio CDi DriveCore 4|600 Power Amplifier

Name: Crown Audio CDi 4|600BL 4-Channel Power Amplifier with BLU Link (600W)
Brand: Crown
SKU: NCDI4X600BL-U-UK
Price: 12286.55 AED
Availability: InStock

The 600W Crown Audio CDi 4|600 4-Channel DriveCore Series Power Amplifier brings engineering excellence to your medium-sized installation needs, from cinemas to houses of worship and bars. It encompasses DriveCore technology for superior efficiency and reliability while being simple to operate, featuring a front-panel interface and network control & monitoring capabilities.

This amplifier eliminates the variability of components thanks to its integrated circuit design, providing remarkable audio fidelity. Comprehensive and customizable options include JBL speaker tunings and an advanced DSP circuit. The unit also streamlines installations with 256 channels of BLU Link digital audio transport over CAT 5e cabling, supporting efficient system setups.

Key Features

DriveCore Technology: Improved performance and reliability by consolidating hundreds of discrete circuits into a single chip.
Network and Control: Equipped with BLU Link RJ45 connectors for 256 audio channels and supports HiQnet Audio Architect software for TCP/IP network control.
Advanced DSP Functionality: Includes input/output EQ filters, crossovers, LevelMAX limiters, and 20 device presets.
Flexible Configurations: Each channel independently configurable for low Z or high Z operation, and can drive up to 100Vrms speaker loads.
Comprehensive Protection Circuits: Protects against shorted outputs, DC, mismatched loads, and thermal or voltage anomalies.
Environmentally Friendly: Complies with Harman’s GreenEdge practices for design, manufacturing, and packaging.

Specifications

Specification	Details
Number of Channels	4
Power Rating	600 W per Channel / 1200 W Bridged
Load Impedance / Voltage	Stereo: 2 / 4 / 8 / 16 Ohms per Channel 70 / 100 V per Channel Bridged: 4 / 8 / 16 Ohms 140 / 200 V
Protections	DC Fault, Low Impedance, Open Circuit, Overcurrent, Overvoltage, Ultrasonic, Undervoltage
Frequency Response	20 Hz to 20 kHz ±0.25 dB (8 Ohms)
Damping Factor	> 1000
Input Sensitivity	Line: 0.7 Vrms to 2.5 Vrms / -0.8 dBu to 10.2 dBu (at 8 Ohms) 1 Vrms to 3.5 Vrms / 2.2 dBu to 13.2 dBu (at 70 V) 1.4 Vrms to 5 Vrms / 5.2 dBu to 16.2 dBu (at 100 V)
Input Impedance	10 Kilohms (Balanced) 5 Kilohms (Unbalanced)
Max Gain	34 dB (at 4 Ohms, at 8 Ohms, at 70 V, at 100 V)
Max Input Level	+20 dBu
SNR	> 104 dB
THD	0.35% (at Rated Power)
Intermodulation Distortion	≤ 0.35%
Crosstalk	> 80 dB (Below Rated Power)
CMRR	> 70 dB
DSP	32-Bit Floating Point DSP at 96 kHz
Audio Delay	Adjustable Up to 1000 ms per Channel
Crossover	High-Pass: 16 to 20 kHz, 12/24/48 dB/Octave Bessel, 16 to 20 kHz, 6/12/24/48 dB/Octave Butterworth, 16 to 20 kHz, 12/24/48 dB/Octave Linkwitz-Riley; Low-Pass: 16 to 20 kHz, 12/24/48 dB/Octave Bessel, 6/12/24/48 dB/Octave Butterworth, 12/24/48 dB/Octave Linkwitz-Riley
EQ	8-Band Parametric EQ per Channel
Limiting	Yes
I/O	2 x Block 6-Pin Balanced Line Input; 2 x Barrier Strip 4-Pin Speaker Output
Digital I/O	1 x RJ45 Ethernet Input/Output (Control); 2 x RJ45 BLU-Link Input/Output (I/O)
USB	None
AC Input Power	Universal: 100 to 240 VAC, 50 / 60 Hz
AC Power Connector	1 x IEC 15 A / NEMA 5-15
Current Consumption	120 VAC: 4.1 to 4.5 A (1/8 Power); 5 to 9.8 A (1/3 Power); 230 VAC: 2 to 2.3 A (1/8 Power); 2.7 to 5.1 A (1/3 Power)
Power Consumption	120 VAC: 201 to 225 W (1/8 Power); 178 to 434 W (1/3 Power); 230 VAC: 144 to 213 W (1/8 Power); 169 to 443 W (1/3 Power)
Display & Indicators	Front Panel: 1 x Multi-Color Graphic LCD
Rackmount Size	2 RU
Cooling	Fan (Variable Speed)
Thermal Dissipation	1512 BTU/hr (Maximum)
Dimensions (WxHxD)	19.0 x 3.5 x 12.2″ / 48.3 x 8.9 x 31.1 cm
Weight	16.3 lb / 7.4 kg
Package Weight	21.1 lb
Box Dimensions (LxWxH)	21.8 x 18.7 x 7.9″
