Crown CDi 4|600 4-Channel Power Amplifier 600W per Channel

Crown

AED 10,978.80 inc VAT.

In stock
Enquiry On Whatsapp
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: NCDI4X600-U-EU Categories: , , Brand:

The 600W Crown Audio CDi 4|600 4-Channel DriveCore Series Power Amplifier features technology from Crown’s DriveCore Install series, offering high-performance and reliability for medium-sized installations like cinemas, houses of worship, and bars. It integrates a versatile DSP circuit, network control, and advanced audio tuning, driving up to 100Vrms speaker loads without a transformer, and includes JBL speaker presets and an Ethernet port for seamless configuration.

Description

Key Features

Specification Details
Number of Channels 4
Power Rating 600 W per Channel, 1200 W Bridged
Load Impedance / Voltage Stereo: 2 / 4 / 8 / 16 Ohms per Channel, 70 / 100 V per Channel Bridged: 4 / 8 / 16 Ohms, 140 / 200 V
Protections DC Fault, Low Impedance, Open Circuit, Overcurrent, Overvoltage, Ultrasonic, Undervoltage
Frequency Response 20 Hz to 20 kHz ±0.25 dB (8 Ohms)
Damping Factor > 1000
Input Sensitivity Line: 0.7 Vrms to 2.5 Vrms / -.8 dBu to 10.2 dBu (at 8 Ohms) 1 Vrms to 3.5 Vrms / 2.2 dBu to 13.2 dBu (at 70 V) 1.4 Vrms to 5 Vrms / 5.2 dBu to 16.2 dBu (at 100 V)
Input Impedance 10 Kilohms (Balanced) 5 Kilohms (Unbalanced)
Max Gain 34 dB (at 4 Ohms, at 8 Ohms, at 70 V, at 100 V)
Max Input Level +20 dBu
SNR > 104 dB
THD 0.35% (at Rated Power)
Intermodulation Distortion ≤ 0.35%
Crosstalk > 80 dB (Below Rated Power)
CMRR > 70 dB
DSP 32-Bit Floating Point DSP at 96 kHz
Audio Delay Adjustable Up to 1000 ms per Channel
Crossover High-Pass: 16 to 20 kHz, 12/24/48 dB/Octave Bessel High-Pass: 16 to 20 kHz, 6/12/24/48 dB/Octave Butterworth High-Pass: 16 to 20 kHz, 12/24/48 dB/Octave Linkwitz-Riley Low-Pass: 16 to 20 kHz, 12/24/48 dB/Octave Bessel Low-Pass: 16 to 20 kHz, 6/12/24/48 dB/Octave Butterworth Low-Pass: 16 to 20 kHz, 12/24/48 dB/Octave Linkwitz-Riley
EQ 8-Band Parametric EQ per Channel
Limiting Yes
I/O 2 x Block 6-Pin Balanced Line Input 2 x Barrier Strip 4-Pin Speaker Output
Digital I/O 1 x RJ45 Ethernet Input/Output (Control)
USB None
AC Input Power Universal: 100 to 240 VAC, 50 / 60 Hz
AC Power Connector 1 x IEC 15 A / NEMA 5-15
Current Consumption 120 VAC: 4.1 to 4.5 A (1/8 Power) 5 to 9.8 A (1/3 Power) 230 VAC: 2 to 2.3 A (1/8 Power) 2.7 to 5.1 A (1/3 Power)
Power Consumption 120 VAC: 201 to 225 W (1/8 Power) 178 to 434 W (1/3 Power) 230 VAC: 144 to 213 W (1/8 Power) 169 to 443 W (1/3 Power)
Display & Indicators Front Panel: 1 x Multi-Color Graphic LCD
Rackmount Size 2 RU
Cooling Fan (Variable Speed)
Thermal Dissipation 1512 BTU/hr (Maximum)
Dimensions 19.0 x 3.5 x 12.2″ / 48.3 x 8.9 x 31.1 cm
Weight 16.3 lb / 7.4 kg
Package Weight 19.87 lb
Box Dimensions (LxWxH) 22 x 19 x 8″
