Crown Audio CDi 4|1200BL 4-Channel DriveCore Series Power Amplifier with BLU Link 1200W

Crown

AED 15948.45 inc VAT.

The 1200W Crown Audio CDi 4|1200 4-Channel DriveCore Series Power Amplifier incorporates technology from the DriveCore Install series, featuring high performance, comprehensive functionalities, and affordability. Key features include a DriveCore integrated circuit, network control and monitoring, advanced DSP, user-friendly front panel, and BLU Link connectors for 256 audio channels. The unit supports 100Vrms speaker loads without a transformer, includes JBL speaker tunings, and offers Ethernet connectivity for HiQnet Audio Architect software.

In stock
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: NCDI4X12BL-U-EU Categories: , , Brand:

Description

Product Overview

The 1200W Crown Audio CDi 4|1200 4-Channel DriveCore Series Power Amplifier with BLU Link offers powerful and reliable audio performance, making it ideal for large installations like cinemas, houses of worship, and hotels. This amplifier incorporates advanced technology to ensure high fidelity and efficiency.

Key Features

  • Patented DriveCore Technology for enhanced performance and reliability.
  • BLU link digital audio transport for up to 256 channels of audio over CAT 5e cables.
  • Configurable and controllable using HiQnet Audio Architect software.
  • Comprehensive network control and monitoring capabilities.
  • Advanced DSP circuit and user-friendly front-panel interface for easy operation.
  • Equipped with an Ethernet port and BLU Link RJ45 connectors.
  • Direct drive capability for 100Vrms speaker loads without transformers.
  • Pre-loaded with JBL speaker tunings for quick installations.
  • Includes a range of protection circuits for reliable operation.
  • Environmentally friendly with GreenEdge compliance.

Specifications

Specification Details
Number of Channels 4
Power Rating 1200 W per Channel
2400 W Bridged
Load Impedance / Voltage Stereo: 2/4/8/16 Ohms per Channel, 70/100 V per Channel
Bridged: 4/8/16 Ohms, 140/200 V
Protections DC Fault, Low Impedance, Open Circuit, Overcurrent, Overvoltage, Ultrasonic, Undervoltage
Frequency Response 20 Hz to 20 kHz ±0.25 dB (8 Ohms)
Damping Factor > 1000
Input Sensitivity 0.7 Vrms to 5 Vrms depending on load
Input Impedance 10 kΩ (Balanced), 5 kΩ (Unbalanced)
Max Gain 34 dB
Max Input Level +20 dBu
SNR > 104 dB
THD 0.35%
Intermodulation Distortion ≤ 0.35%
Crosstalk > 80 dB
CMRR > 70 dB
DSP 32-Bit Floating Point DSP at 96 kHz
Audio Delay Adjustable up to 1000 ms per Channel
EQ 8-Band Parametric EQ per Channel
Limiting Yes
I/O 2 x 6-Pin Balanced Line Input, 2 x 4-Pin Speaker Output
Digital I/O 1 x RJ45 Ethernet Input/Output, 2 x RJ45 BLU-Link Input/Output
USB None
AC Input Power 100 to 240 VAC, 50/60 Hz
Current Consumption Varies with power usage
Power Consumption Varies with power usage
Thermal Dissipation 1865 BTU/hr (Maximum)
Dimensions 19.0 x 3.5 x 14.7″ (48.3 x 8.9 x 37.4 cm)
Weight 20.1 lb (9.1 kg)
