Powered Amplifiers

Crown Audio CDi 2-Channel DriveCore Series Power Amplifier with BLU Link (1200W)

Crown

AED 10566.96 inc VAT.

The 1200W Crown Audio CDi 2|1200 2-Channel DriveCore Series Power Amplifier with BLU Link is designed for large installation applications such as cinemas and houses of worship. Featuring technology from Crown’s DriveCore Install series, this amplifier offers high performance, advanced DSP circuitry, and network control. It includes BLU Link connectivity for 256 audio channels, can drive up to 100Vrms speaker loads without a transformer, and is pre-loaded with JBL speaker tunings for efficient setup. Configuration is facilitated via an Ethernet port using HARMAN’s HiQnet Audio Architect software.

In stock
Request Quote
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: NCDI2X12BL-U-UK Categories: , , Brand:

Description

Crown Audio CDi 2|1200 2-Channel DriveCore Series Power Amplifier with BLU Link

The Crown Audio CDi 2|1200 2-Channel DriveCore Series Power Amplifier with BLU Link is an innovative solution for powerful and efficient audio amplification in large installation environments such as cinemas, houses of worship, hotels, and cruise lines. Utilizing advanced DriveCore technology, this amplifier provides high-performance audio fidelity and robust features at a competitive cost.

This state-of-the-art amplifier integrates network control and monitoring, an advanced DSP circuit, and an intuitive front-panel interface, all designed to simplify your audio setup process. With two BLU Link RJ45 connectors capable of transmitting up to 256 fault-tolerant audio channels, the CDi 2|1200 ensures a seamless and reliable audio experience.

Features

  • DriveCore Technology: Enhances performance, reduces power consumption, and increases reliability.
  • BLU Link: Capable of handling up to 256 digital audio channels over CAT 5e cabling.
  • HiQnet Audio Architect: Enables configuration and control over a TCP/IQ network.
  • Advanced DSP Circuit: Includes input/output EQ filters, crossovers, delays, and limiters.
  • LCD Interface: User-friendly front-panel interface for configuration and monitoring.
  • Universal Power Supply: Features PFC for reduced current draw and improved efficiency.
  • Pre-loaded JBL Tuning: Features for quick and easier installation.

Specifications

Specification Details
Number of Channels 2
Power Rating 1200 W per Channel
Load Impedance / Voltage Stereo: 2 / 4 / 8 / 16 Ohms per Channel
70 / 100 V per Channel
Bridged: 4 / 8 / 16 Ohms
140 / 200 V
Protections DC Fault, Low Impedance, Open Circuit, Overcurrent, Overvoltage, Ultrasonic, Undervoltage
Frequency Response 20 Hz to 20 kHz ±0.25 dB (8 Ohms)
Damping Factor > 1000
Input Sensitivity Line: 0.7 Vrms to 2.5 Vrms / -.8 dBu to 10.2 dBu (at 8 Ohms)
1 Vrms to 3.5 Vrms / 2.2 dBu to 13.2 dBu (at 70 V)
1.4 Vrms to 5 Vrms / 5.2 dBu to 16.2 dBu (at 100 V)
Input Impedance 10 Kilohms (Balanced)
5 Kilohms (Unbalanced)
Max Gain 34 dB (at 4 Ohms, at 8 Ohms, at 70 V, at 100 V)
Max Input Level +20 dBu
SNR > 104 dB
THD 0.35% (at Rated Power)
Intermodulation Distortion ≤ 0.35%
Crosstalk > 80 dB (Below Rated Power)
CMRR > 70 dB
DSP 32-Bit Floating Point DSP at 96 kHz
Audio Delay Adjustable Up to 1000 ms per Channel
Crossover High-Pass: 16 to 20 kHz, 12/24/48 dB/Octave Bessel/Butterworth/Linkwitz-Riley.
Low-Pass: 16 to 20 kHz, 12/24/48 dB/Octave Bessel/Butterworth/Linkwitz-Riley.
EQ 8-Band Parametric EQ per Channel
Limiting Yes
AC Input Power Universal: 100 to 240 VAC, 50 / 60 Hz
Power Consumption 120 VAC: 130 to 167 W (1/8 Power), 204 to 265 W (1/3 Power).
230 VAC: 117 to 149 W (1/8 Power), 196 to 313 W (1/3 Power).
Dimensions 19.0 x 3.5 x 14.7″ / 48.3 x 8.9 x 37.4 cm
Weight 17.2 lb / 7.8 kg
