Amplifiers

Bose Professional Freespace IZA 190-Hz Zone Amplifier 90W (70/100V)

Bose Professional

AED 2510 inc VAT.

The IZA 190-HZ integrates signal processing, routing, paging, and amplification in a single 90W Euroblock output with 70 and 100V leads, featuring versatile input connections (mic/line/page), gain and level adjustments, and multiple modes, and offers enhanced sound optimization with FreeSpace FS2 and FS4 loudspeakers through onboard EQ presets.

In stock
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: IZA190HZ-EQ-UK Categories: , Brand:

Description

Key Features

System integrators looking for a simple-to-use background/foreground music and paging amplifier will be impressed with Bose Professional IZA 190-HZ, an integrated zone amplifier that’s well suited for retail stores, restaurants, bars, hospitality venues, conference centers, schools, and auxiliary zones. The IZA 190-HZ delivers premium sound, provides a simplified setup, and easy daily operation and offers the flexibility to expand when additional loudspeakers are required.

The IZA 190-HZ features signal processing, routing, paging, and amplification on a single 90W Euroblock speaker output with separate leads for 70 and 100V. The unit offers a variety of easy-to-use input connections (mic/line/page), input gain and output level adjustments, and operational modes. When used with FreeSpace FS2 and FS4 loudspeakers, even further sound optimization is possible through onboard selectable EQ presets.

Feature Highlights

  • Class-D amplifier delivers optimized performance with high-quality sound.
  • Easy setup through front and rear panels without needing a computer.
  • Opti-voice paging for smooth transitions between music and page signals.
  • User-friendly front panel for easy device connections and adjustments.
  • Compact design suitable for various placement options.

Specifications

Specification Details
Number of Channels 1
Power Rating 70 V / 100 V: 1 x 90 W
Protections Short Circuit, Thermal
Frequency Response 60 Hz to 20 kHz +0/-3 dB (at 1 W)
Input Impedance 20 Kilohms
Max Input Level +10 dBV
THD+N < 0.3% (at Rated Power)
Crosstalk ≤ -60 dBu (Below Rated Power, 1 kHz)
Sample Rate 48 kHz
AD/DA Conversion 24-Bit
DSP Yes
Latency 10.4 ms (Analog Input to Output)
EQ 2-Band Shelving EQ
Connectivity 1 x Combo XLR-1/4″ 3-Pin Female Balanced/Unbalanced Line/Mic Input
1 x 1/8″ / 3.5 mm TRS Female Unbalanced Aux Input
1 x Block 4-Pin Page
2 x 2RCA TS Female Unbalanced Line
1 x Block 4-Pin Remote Input
1 x Block 2-Pin Mute
1 x Block 3-Pin Speaker Output
1 x 2RCA TS Female Aux Output
AC Input Power 100 to 240 VAC, 50 / 60 Hz
AC Power Connector IEC
Current Consumption (Max) 230 VAC: 7.6 A / 120 VAC: 13.9 A
Power Consumption 15 W (Standby) / 200 W (Max)
Display & Indicators Blue LED (Power/Standby), Red LED (Clip/Input/Signal)
Rackmount Size 1 RU (1/2-Rack)
Cooling Convection
Dimensions 8.4 x 1.8 x 12.2″ / 213.4 x 45.7 x 309.9 mm
Weight 7 lb / 3.2 kg
Package Weight 9 lb
Box Dimensions 18.1 x 11.1 x 4.1″
