Allen & Heath XONE:PX5 6-Channel Analog DJ Mixer with FX and USB Soundcard

Allen & Heath

AED 7,189 inc VAT.

In stock
Enquiry On Whatsapp
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: XONE:PX5 Categories: , , Brand:

The XONE:PX5 by Allen & Heath is a premium 4+1 channel DJ mixer featuring a built-in sound card, XONE analog filter with resonance control, 3-band EQ, replaceable VCA crossfader, X:FX send and return, and the XONE:Xcite FX suite, which includes performance-oriented delays, reverbs, modulators, flangers, and distorters, all accessible via intuitive hands-on controls.

Description

Xone:PX5 DJ Mixer

Combining the signature warm analogue Xone sound with world-class digital connectivity, the Xone:PX5 breathes life into electronic music performance. The built-in FX technology offers unparalleled manipulation, featuring the Xone:Xcite FX suite of delays, reverbs, modulators, flangers, and distorters, all assignable through simple hands-on control for fine-tuning and creative expression.

This 4+1 channel mixer is equipped with the legendary Xone filter, a 3-band EQ on all channels, and an intuitive layout. The versatile Send/Return feature allows for the connection of external FX hardware with Send/Return and Master Insert mode connections (Line or Hi-Z). Each channel has its dedicated send control for external FX processing, which can also be routed to the internal Xone:FX engine.

For seamless digital DJ integration, connect your laptop to the 20-channel 24bit 96kHz USB2 soundcard. The crossfader has three switchable curve settings perfect for blending or scratching styles and can be upgraded to an Innofader Pro 2.

Key Specifications

Specification Details
Type Analog
Channels 4 + 1
EQ 3-band / Total Kill (CH 1-4 + CH A)
USB Soundcard 20 Channel (10 in / 10 out)
USB2 / Class Compliant
24bit / 96kHz
1 x MIDI IN
1 x MIDI Out
Line Inputs 4 x RCA (CH 1-4)
1 x 1/4″ TRS (CH A) Mono/Stereo
Phono Inputs 4 x RCA (CH 1-4)
LN/PH Switch for DVS
USB Inputs 5 x USB (CH 1-4 + CH A)
Mic Input 1 x XLR
Master Output 1 x XLR (Balanced)
Master 2 Output 1 x RCA (Un-balanced)
Booth Output 1 x 1/4″ TRS
Record Output 1 x RCA (Un-balanced)
Master Insert 1 x 1/4″ TRS
MIDI Sync/Out 1 x 5-Pin DIN
DIN Offset Control
Send/Return I/O 1 x 1/4″ TRS Send
1 x 1/4″ TRS Return
1 x LN/Hi-Z Switch
Internal Xone:FX Yes
Hybrid FX Mode Yes (Internal < Dual > External)
FX Send 1 x Pre/Post Selectable (CH 1-4 + CH A)
Filter 1 x VCF Filter
HPF / BPF / LPF
Adjustable Frequency & Resonance
Assignable CH 1-4 + CH A + External Return
X-Link 1 x RJ45
Headphones 1 x 1/4″
1 x 3.5mm
Split Cue Monitoring
Channel Faders 60mm VCA / Replaceable
Chanel Meters 12 Segment LED
Channel Fader Curve 3 Types
X-Fader 45mm VCA / Replaceable / Innofader Compatible
X-Fader Curve Settings 3 Types
MIDI Clock Send + Receive
Start / Stop / Pause / Tempo Bend (-/+)
MIDI Assignable Yes (MIDI CC / MIDI Notes)
BPM Detection Auto / Manual / Tap Tempo
Earth Ground Terminals 2 x 2
Headroom 20dB
AC Mains 100 to 240V
AC 50/60Hz
Consumption 35W max
Mains Adaptor 3 pin IEC socket with cable clamp
Fuse Rating 250V AC T1AL 20mm
Height 4.3″
Width 12.6″
Depth 14.8″
Weight 11.5 lbs.
