Allen & Heath Qu-SB Ultra Compact Digital Mixer, 16 Mic/Line Inputs, 1 Stereo Line, 4 FX, 12 Mixes, iPad-Controlled

Allen & Heath

AED 5970 inc VAT.

The Allen & Heath Qu-SB is an 18-in/14-out digital mixer and 32×32 USB recording interface, featuring 16 recallable AnalogiQ microphone preamps and a 5-core ARM processor. It includes integrated effects like 4-band parametric EQs, compressors, delay, and reverb. Compatible with the ME Personal Mixing System and dSNAKE digital connectivity, it supports up to 38 inputs. Controlled via the Qu-Pad app on an iPad, it allows wireless mixing throughout the venue.

In stock
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: QU-SB Categories: , , Brand:

Description

Qu-SB Digital Mixer

The Qu-SB is an ultra-compact digital mixer designed for flexibility and portability. Perfect for performing bands and artists, the Qu-SB allows you to mix from anywhere within the venue, offering an intuitive and portable alternative to traditional analog mixers. Loaded with highly acclaimed FX emulations and dynamics, it serves as a comprehensive solution to suit your professional needs.

With the Qu-Pad app, you can set up shows and mix live from your iPad, while the customizable Qu-Control app provides essential controls for easy access during performances. Furthermore, the Qu-You personal monitoring app for both Android and iOS ensures a consistent and high-quality sound experience throughout performances.

The mixer supports multi-track recording and playback, providing the ability to recall settings from previous shows for virtual soundchecks. The Qu-SB also features 18 onboard inputs and 14 outputs and can be expanded up to 38 inputs and 24 outputs using the remote AudioRacks.

Features

  • 16 local Mono Mic/Line Inputs (TRS + XLR)
  • Recallable AnaLOGIQ™ Preamps
  • 1 Stereo Input (TRS)
  • 12 local Mix Outputs (XLR)
  • 1 Stereo Output (TRS)
  • Expandable up to 32 inputs, 24 outputs using dSNAKE AudioRack
  • Up to 11 Monitor Mixes (4 mono + 7 stereo)
  • 4 Stereo Groups (switchable to Mix mode)
  • 4 FX Engines
  • 4 dedicated FX Sends/Returns
  • 4 Mute Groups
  • 4 DCA Groups
  • 32×32 USB Audio Interface
  • Qu-Drive Multitrack Recording/Playback direct to USB device
  • dSNAKE™ Remote Audio Port
  • Qu-Pad fully-featured iPad App
  • Qu-You iPhone/Android personal monitoring app
  • Qu-Control customizable iOS app for simple wireless control

Specifications

Specification Details
Number of Analog Input Channels 16
Mix Routing 4 x Stereo FX Return
Groups 4 x Mute Group, 4 x DCA Group
Meter Range -48 to -3 dBFS Peak/Clip (+19 dBu at XLR Output)
Meter Calibration 0 dB on Meter = -18 dBFS (+4 dBu at XLR Output)
Gain/Trim Range Line: ±24 dB (Stereo Channels), Mic/Line: -5 dB to +60 dB (1 dB Steps)
Input Polarity Normal/Reverse
Gate Parameters Threshold: -72 to +18 dBu, Depth: 0 to 60 dB, Attack: 50 μs to 300 ms, Hold: 10 ms to 5 sec, Release: 10 ms to 1 sec
Compressor Parameters Threshold: -46 to 18 dBu, Ratio: 1:1 to ∞:1, Attack: 300 μs to 300 ms, Release: 100 ms to 2 sec, Knee: Soft/Hard
EQ FX Returns: 4-Band Parametric
Graphic EQ 28-Band 1/3 Octave, ±12 dB 31 Hz to 16 kHz
Filters High-Pass: 20 Hz to 20 kHz, 12 dB/Octave
Channel Output/Source Monitoring AFL, PFL, Post-Preamp, Post-EQ, Post-FX
Built-In Effects Reverb, Delay, Gated Reverb, ADT, Chorus, Phaser, Flanger
Real Time Analyzer 31-Band 1/3 Octave, 20 Hz to 20 kHz
Sample Rates 48 kHz
Bit Depth 24-Bit Delta Sigma Conversion
Latency 1.2 ms (Mic Input to XLR Output), 0.7 ms (Mic Input to AES Output)
Dimensions 19 x 5.3 x 7″ (Rack-Mounted)
Weight 12.7 lb
