AKG DMM14 U Digital Microphone Mixer with 140 Channels Capacity

AKG

AED 15,991.50 inc VAT.

In stock
Enquiry On Whatsapp
  • Check Mark Estimated Delivery: 2–3 business days across the UAE
  • Check Mark Free Shipping & Returns : On all orders over AED 1000
  • Stripe
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: DMM14 U Categories: , , Brand:

The DMM14 U Digital Automatic Microphone Mixer by AKG is a professional mixer designed for large meetings and conferences, featuring DSP functions for precise mixing of up to 140 channels with high signal-to-noise ratio, and offering two additional stereo audio outputs and one stereo USB for flexible routing options.

Description

The DMM14 U Digital Automatic Microphone Mixer from AKG is a professional microphone mixer ideal for use in large meetings and conferences. Its DSP function ensures precise mixing of up to 140 channels by cascading up to ten DMM14 U mixers. Two additional stereo audio outputs and one stereo USB offer additional routing options. Due to high signal-to-noise ratio, the DMM14 U also keeps noise from multiple open microphones to a minimum. Numerous DSP functions such as filters, compressor/limiter, ducking, and routing make the DMM14 U suitable for a variety of spoken word applications.

Key Features

  • 12-band graphic EQ on outputs for optimized loudspeaker tuning
  • Six programmable presets for easy tailoring to different situations
  • Two-channel USB streaming for seamless IT network integration
  • Up to ten units can be cascaded for simultaneous use of up to 140 channels
  • Digital signal processing and sophisticated mixing algorithms for wireless multimedia presentations
  • Audio matrix routing of all inputs to all outputs for diverse mix creation
  • Made in Germany

Specifications

Input Channels 12 x Phoenix, Line/Microphone/Aux/Mono, 2 x USB channels
Output Channels 6 x Analog (output 1), 6 x Analog (output 2), 6 x Analog (record), 2 x USB channels
DSP Functions Treble, bass, low-cut, limiter, compressor, automix, priority, pan/balance, delay
Phantom Power 48 V maximum, 10 mA per input
Type Symmetrical
Level -60 dBu to 0 dBu
Frequency Range +/-3 dB, 20 Hz – 20 kHz
THD & Noise < 0.1%
Noise Level < -120 dBu (22 Hz – 22 kHz, QPK)
Dynamics > 100 dB
Distortion 20 dB
S/N Ratio > 90 dB (22 Hz – 22 kHz, RMS, A-Filter)
